Specifications
Brand Name :
FANBAO
Certification :
CE
Place of Origin :
china
MOQ :
1
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
150sets per month
Delivery Time :
5-8 work days
Packaging Details :
standard export wooden case
mixing tank size :
100L to 20000L
mixer power :
1.5kw-11kw. or customizable
Homogenizer Speed :
2940RPM
Material :
Stainless Steel
Surface Finish :
Mirror Polish
Supporting Legs :
Adjustable
Motor Power :
0.55-55KW
Control System :
PLC
Heating Method :
Electric Heating
Application :
Food, Beverage, Pharmaceutical, Chemical, etc.
Tank Shape :
Cylindrical
Mixing Mode :
Continuous
Description

Homogenizer Tank Mixer Jacketed Stainless Steel Mixing Tank With Agitator

Description:

High-speed emulsification tank is the most advanced blending equipment in the fields of dairy products, beverages,
fruit juice and foods etc. When the high-speed super-fine emulsification paddle works, it throws the materials in the center of rotor to stator at a high speed, then through teeth clearance of stator and shearing, collision and crushing between rotor and stator, the super-fine emulsification is realized. Therefore, it is an integrated equipment comprising multi-function such as blending, emulsifying, homogenizing, solving and smashing etc.

Operating principle

The mixer's high speed and precise rotor-stator tolerances create significant suction, drawing the product from the tank's bottom to the head's center. Subsequently, the rotor propels the product radially from the lower part of the head. As the product passes through the stator's openings, it undergoes mechanical shearing, with particles sheared by the rotor at 20 m/s. Exiting the stator through high-speed slots, the product experiences hydraulic shearing.

Simultaneously, the product returns to the working head, ensuring a continuous mixing cycle and fostering robust circulation within the tank. The vertical suction combined with radial thrust establishes a circulating flow. With proper mixer sizing and power selection, the tank's ingredients circulate through the working head numerous times, facilitating gradual and uniform homogenization.

An essential feature is the mixer's ability to minimize product aeration, preserving product integrity.

Homogenizer Mixing Tanks Stainless Steel Jacketed With Agitator Custom

Homogenizer Mixing Tanks Stainless Steel Jacketed With Agitator Custom

Stainless steel mixing tank size for client's choice

Stainless Steel Mixing Tank ——customized
Profile/type Singlelayer tank Double layers tank Three layers tank
Material SS304L SS316L
Volume 100L---20000L
Tank Type Vertical type Horizontal type Mobile type
Structure one layer Innerlayer+jacket inner
layer+jacket+insulation
heating way Electric Heating
Steam Heating
Inside Finish Mirror polished Ra<0.4um (customer requirement)
Outside Finish 2B Satin Finish
Stirrer type impeller,Anchor ,Turbine ,High shear,magnetic mixer,Anchor mixer with
scraper
Power 0.55~55KW
Voltage 110V~480V
Top Head type Dish top,Open lid top,Flat top
Bottom type Dish bottom,Conical bottom,Flat bottom
PARTS DETAILS 1.Quick open manhole /Pressure manhole
2.Various types of CIP cleaners
3.Sterile respirator
4.Adjustable Legs
5.Inlet and Outlet sanitary valve
6.Thermometer (According to customer requirements)
7.Paddle blender . (According to customer requirements)
8.Liquid level meter and lever controller (According to customer requirements)
9.Ladder
Application Food,Beverage,pharmacy,biological,honey,chocolate,alcohol ,chemical
industry etc
We can customize the mixing equipment according to customer requirements.

Homogenizer Mixing Tanks Stainless Steel Jacketed With Agitator CustomHomogenizer Mixing Tanks Stainless Steel Jacketed With Agitator Custom

Homogenizer Mixing Tanks Stainless Steel Jacketed With Agitator Custom

HEATING/MIXING/HOMOGENIZER

Type Heater (KW)
Mixer (KW)
Mixer Speed
(RPM)
Homogenizer
(KW)
Homogenizer
Speed (RPM)
DFM-200L 6 1.5 0-63 4 2890
DFM-300L 9 2.2 0-63 4 2890
DFM-500L 18 3-4 0-63 5.5 2900
DFM-1000L 27KW/steam 4-5.5 0-63 7.5 2900
DFM-2000L 27KW/steam 5.5 0-63 11 2930
DFM-3000L 36KW/steam 7.5 0-63 15 2930
DFM-5000L 48KW/steam 11 0-63 22 2940
customizable customizable customizable customizable customizable customizable
