F Series 10hp Helical Gear Reducer AC Electrical Motors Speed Reducer With IEC Flange
F Series 10hp Helical Gear Reducer AC Electrical Motors Speed Reducer With IEC Flange
F Series 10hp Helical Gear Reducer AC Electrical Motors Speed Reducer With IEC Flange
F Series 10hp Helical Gear Reducer AC Electrical Motors Speed Reducer With IEC Flange
F Series 10hp Helical Gear Reducer AC Electrical Motors Speed Reducer With IEC Flange
F Series 10hp Helical Gear Reducer AC Electrical Motors Speed Reducer With IEC Flange
Specifications
Brand Name :
FANBAO
Model Number :
F37, F47, F57, F67, F77, F87, F97, F107, F127, F157 FA37, FA47, FA57, FA67, FA77, FA87, FA97, FA107, FA127, FA157 FF37, FF47, FF57, FF67, FF77, FF87, FF97, FF107, FF127, FF157 FAF37, FAF47, FAF57, FAF67, FAF77, FAF87, FAF97, FAF107, FAF127, FAF157
Certification :
CE
Place of Origin :
china
MOQ :
1
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
100sets per month
Delivery Time :
8-15work days
Packaging Details :
standard export wooden case
Output Torque :
10.6-952000NM
Input Speed :
750-1500rpm
Output Speed :
14-280rpm
Warranty :
1 year
Color :
customer Requirement
Ratio :
3.77~276.77
Efficiency :
94%~98%(depends on the transmission stage)
Mounting Position :
Flange, hollow shaft, solid shaft
Certificate :
ISO9001. CE
Applicable Industries :
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Home Use, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
Material :
Gear: 20CrMnTi Housing: HT250 high strength cast iron
product name :
F57 F157 Series 10hp AC Electrical Gear Motors Speed Reducer With IEC Flange
Description

F57 F157 Series 10hp AC Electrical Gear Motors Speed Reducer With IEC Flange

Description :

The F Series reducer is meticulously crafted to meet stringent international technical standards, showcasing a blend of advanced scientific sophistication. Designed for optimal space utilization, this gear reducer offers reliability, durability, and a high overload capacity, supporting power outputs of 90KW or more.

Featuring a parallel shaft helical design, the F Series gear reducer excels in energy efficiency, boasting over 95% efficiency. Its compact size, lightweight construction, and impressive transfer torque make it a top choice for various installation scenarios. With multi-stage gear units for low output speeds, this reducer can be seamlessly combined with other series like R, K, and S for enhanced torque and reduced speed.

The F Series Gear Reducer's standardized and modularized approach allows for versatile mounting options such as foot-mounted, flange-mounted, and shaft-mounted configurations, ensuring adaptability to diverse setups

Product Feature

• High efficiency and save power.
• High modular design, flexible mounting mode.
• Integrated casting housing,compact dimension, stable transmitting and low noise level.
• Perfect oil leakage preventing makes the good sealings and can be used in wide range of industry.
• Advanced gear grinding and modified profile, high loading support and more safe operation.

Apart of type specification :

Size Shaft Dia. (mm) Center
Height		 Output
Flange
Dia. (mm)		 Power
(kw)		 Ratio Permissible
Torque
(n.m)		 Weight
(kgs)

Solid Hallow
37 φ25k6 φ30h7 76 φ110/160 0.18-3.0 3.81-128.51 200 13
47 φ30k6 φ35h7 77 φ120/200 0.18-3.0 5.06-189.39 400 18
57 φ35k6 φ40h7 93 φ155/250 0.18-5.50 5.18-199.70 600 34
67 φ40k6 φ40h7 97 φ155/250 0.18-5.50 4.21-228.91 820 55
77 φ50k6 φ50h7 121 φ170/300 0.37-11.0 4.30-281.71 1500 90
87 φ60m6 φ60h7 152 φ215/350 0.75-22.0 4.12-270.68 3000 150
97 φ70m6 φ70h7 178 φ260/450 1.10-30.0 4.68-280.76 4300 260
107 φ90m6 φ90h7 200 φ304/450 2.20-45.0 6.20-254.40 7840 402
127 φ110m5 φ100h7 236 φ350/550 7.5-90.0 4.63-172.17 12000 700
157 φ120m6 φ120h7 286 φ400/660 11.0-200.0 11.92-267.43 18000 950

Application :

Industrial Machine: Food Stuff, Ceramics, CHEMICAL, Packing, Dyeing,
Wood working, Glass.

Mounting position and Position of the motor terminal box :

F Series 10hp Helical Gear Reducer AC Electrical Motors Speed Reducer With IEC Flange
F Series 10hp Helical Gear Reducer AC Electrical Motors Speed Reducer With IEC Flange
F Series 10hp Helical Gear Reducer AC Electrical Motors Speed Reducer With IEC FlangeF Series 10hp Helical Gear Reducer AC Electrical Motors Speed Reducer With IEC FlangeF Series 10hp Helical Gear Reducer AC Electrical Motors Speed Reducer With IEC FlangeF Series 10hp Helical Gear Reducer AC Electrical Motors Speed Reducer With IEC Flange

Why choose us :

F Series 10hp Helical Gear Reducer AC Electrical Motors Speed Reducer With IEC FlangeF Series 10hp Helical Gear Reducer AC Electrical Motors Speed Reducer With IEC FlangeF Series 10hp Helical Gear Reducer AC Electrical Motors Speed Reducer With IEC Flange

F series process :
F Series 10hp Helical Gear Reducer AC Electrical Motors Speed Reducer With IEC Flange
Packing and shipping way :
F Series 10hp Helical Gear Reducer AC Electrical Motors Speed Reducer With IEC Flange
