Specifications
Brand Name :
FANBAO
Model Number :
F37, F47, F57, F67, F77, F87, F97, F107, F127, F157 FA37, FA47, FA57, FA67, FA77, FA87, FA97, FA107, FA127, FA157 FF37, FF47, FF57, FF67, FF77, FF87, FF97, FF107, FF127, FF157 FAF37, FAF47, FAF57, FAF67, FAF77, FAF87, FAF97, FAF107, FAF127, FAF157
Certification :
CE
Place of Origin :
china
MOQ :
1
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
100sets per month
Delivery Time :
8-15work days
Packaging Details :
standard export wooden case
Output Torque :
10.6-952000NM
Input Speed :
750-1500rpm
Output Speed :
14-280rpm
Warranty :
1 year
Color :
customer Requirement
Ratio :
3.77~276.77
Efficiency :
94%~98%(depends on the transmission stage)
Mounting Position :
Flange, hollow shaft, solid shaft
Certificate :
ISO9001. CE
Applicable Industries :
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Home Use, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
Material :
Gear: 20CrMnTi Housing: HT250 high strength cast iron
product name :
Precision Crafted F Series Parallel Shaft Helical Gearbox Reducer For Automotive Assembly Lines
Description

Precision Crafted F Series Parallel Shaft Helical Gearbox Reducer For Automotive Assembly Lines

Description :

the Helical Gearbox Reducer F Series Gear Reducer, renowned for its parallel output design. This innovative unit seamlessly integrates standardization and modularization, ensuring compatibility with leading international brands while maintaining structural rigidity and compactness. Embodying a modular design and compact structure, these gear reducers are ideal for applications where space is at a premium.

The F Series parallel shaft helical gear motors find their niche in conveyors and materials processing setups. These multi-stage gear units, available in 2 or 3 stages, cater to low output speed requirements. They feature a hollow output shaft with versatile connection options such as keyed connection, shrink disk, splined hollow shaft, or torque arm.

For enhanced flexibility, these gear reducers can be paired with other gearbox types like the R Series and UDL Series. Additionally, they offer various mounting options including foot-mounted, flange-mounted, and shaft-mounted configurations, providing adaptability to a diverse range of setups.

Apart of type specification :

Size Shaft Dia. (mm) Center
Height		 Output
Flange
Dia. (mm)		 Power
(kw)		 Ratio Permissible
Torque
(n.m)		 Weight
(kgs)

Solid Hallow
37 φ25k6 φ30h7 76 φ110/160 0.18-3.0 3.81-128.51 200 13
47 φ30k6 φ35h7 77 φ120/200 0.18-3.0 5.06-189.39 400 18
57 φ35k6 φ40h7 93 φ155/250 0.18-5.50 5.18-199.70 600 34
67 φ40k6 φ40h7 97 φ155/250 0.18-5.50 4.21-228.91 820 55
77 φ50k6 φ50h7 121 φ170/300 0.37-11.0 4.30-281.71 1500 90
87 φ60m6 φ60h7 152 φ215/350 0.75-22.0 4.12-270.68 3000 150
97 φ70m6 φ70h7 178 φ260/450 1.10-30.0 4.68-280.76 4300 260
107 φ90m6 φ90h7 200 φ304/450 2.20-45.0 6.20-254.40 7840 402
127 φ110m5 φ100h7 236 φ350/550 7.5-90.0 4.63-172.17 12000 700
157 φ120m6 φ120h7 286 φ400/660 11.0-200.0 11.92-267.43 18000 950

Structure:

a.F—common shaft extension coupling parallel shaft helical gear reducer;
b.FA type—shaft-mounted parallel shaft helical gear reducer;
c.FF type—flanged parallel shaft oblique gear Gear reducer;
d.FAF type-shaft mounted flange type parallel shaft helical gear reducer.

Application :

Industrial Machine: Food Stuff, Ceramics, CHEMICAL, Packing, Dyeing,
Wood working, Glass.

Mounting position and Position of the motor terminal box :

Precision Helical Gear Reducer Parallel Shaft Gearbox For Automotive Assembly Lines
Precision Helical Gear Reducer Parallel Shaft Gearbox For Automotive Assembly Lines
Precision Helical Gear Reducer Parallel Shaft Gearbox For Automotive Assembly Lines
Precision Helical Gear Reducer Parallel Shaft Gearbox For Automotive Assembly LinesPrecision Helical Gear Reducer Parallel Shaft Gearbox For Automotive Assembly LinesPrecision Helical Gear Reducer Parallel Shaft Gearbox For Automotive Assembly Lines

Why choose us :

Precision Helical Gear Reducer Parallel Shaft Gearbox For Automotive Assembly LinesPrecision Helical Gear Reducer Parallel Shaft Gearbox For Automotive Assembly LinesPrecision Helical Gear Reducer Parallel Shaft Gearbox For Automotive Assembly Lines

F series process :
Precision Helical Gear Reducer Parallel Shaft Gearbox For Automotive Assembly Lines
Packing and shipping way :
Precision Helical Gear Reducer Parallel Shaft Gearbox For Automotive Assembly Lines
