Stainless Steel Portable Agitator Mixer Cosmetic High Shear Homogenizer Pneumatic Lifting
Stainless Steel Portable Agitator Mixer Cosmetic High Shear Homogenizer Pneumatic Lifting
Stainless Steel Portable Agitator Mixer Cosmetic High Shear Homogenizer Pneumatic Lifting
Stainless Steel Portable Agitator Mixer Cosmetic High Shear Homogenizer Pneumatic Lifting
Specifications
Brand Name :
FANBAO
Certification :
CE
Place of Origin :
china
MOQ :
1
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
150sets per month
Delivery Time :
5-8 work days
Packaging Details :
standard export wooden case
mixing tank size :
100L to 20000L
mixer power :
1.5kw-11kw. or customizable
Homogenizer :
2930 RMP
Material :
SUS304, SUS304L, SUS316, SUS316L
Surface Finish :
Mirror Polish
Motor Power :
1.5kw
Max. Loading Capacity :
500kg
Heating Method :
Electric Heating
weight :
85kg
Description

Stainless Steel Cosmetic High Shear Pneumatic Lifting Homogenizer Mixer

Description:

Stainless Steel Cosmetic High Shear Pneumatic Lifting Homogenizer Mixer is specially designed for mixing application of oil and water phases in order to produce a homogenous emulsion without separation. It is also widely used for a faster and more efficient dispersion especially when gum such as Carbopol needs to be incorporated without agglomeration problem due to “fish eye”.

At the core of each Batch Processing Mixer unit lies the precision engineered rotor & stator with either single or double vortex design which is key in high shear mixing for efficient emulsifying or homogenizing processes.

Product name
Movable Pneumatic Lifting Homogenizer
Rotation speed
0-3000rpm
Lifting height
900mm
Air pressure
0.4Mpa
Motor power
3kw
Product advantages
Movable, easy to operate, stable operation

Stainless Steel Portable Agitator Mixer Cosmetic High Shear Homogenizer Pneumatic Lifting

Stainless Steel Portable Agitator Mixer Cosmetic High Shear Homogenizer Pneumatic Lifting

Stainless Steel Portable Agitator Mixer Cosmetic High Shear Homogenizer Pneumatic Lifting

Stainless steel mixing tank size for client's choice

Stainless Steel Mixing Tank ——customized
Profile/type Singlelayer tank Double layers tank Three layers tank
Material SS304L SS316L
Volume 100L---20000L
Tank Type Vertical type Horizontal type Mobile type
Structure one layer Innerlayer+jacket inner
layer+jacket+insulation
heating way Electric Heating
Steam Heating
Inside Finish Mirror polished Ra<0.4um (customer requirement)
Outside Finish 2B Satin Finish
Stirrer type impeller,Anchor ,Turbine ,High shear,magnetic mixer,Anchor mixer with
scraper
Power 0.55~55KW
Voltage 110V~480V
Top Head type Dish top,Open lid top,Flat top
Bottom type Dish bottom,Conical bottom,Flat bottom
PARTS DETAILS 1.Quick open manhole /Pressure manhole
2.Various types of CIP cleaners
3.Sterile respirator
4.Adjustable Legs
5.Inlet and Outlet sanitary valve
6.Thermometer (According to customer requirements)
7.Paddle blender . (According to customer requirements)
8.Liquid level meter and lever controller (According to customer requirements)
9.Ladder
Application Food,Beverage,pharmacy,biological,honey,chocolate,alcohol ,chemical
industry etc
We can customize the mixing equipment according to customer requirements.

Stainless Steel Portable Agitator Mixer Cosmetic High Shear Homogenizer Pneumatic LiftingStainless Steel Portable Agitator Mixer Cosmetic High Shear Homogenizer Pneumatic Lifting

Stainless Steel Portable Agitator Mixer Cosmetic High Shear Homogenizer Pneumatic Lifting

HEATING/MIXING/HOMOGENIZER

Type Heater (KW)
Mixer (KW)
Mixer Speed
(RPM)
Homogenizer
(KW)
Homogenizer
Speed (RPM)
DFM-200L 6 1.5 0-63 4 2890
DFM-300L 9 2.2 0-63 4 2890
DFM-500L 18 3-4 0-63 5.5 2900
DFM-1000L 27KW/steam 4-5.5 0-63 7.5 2900
DFM-2000L 27KW/steam 5.5 0-63 11 2930
DFM-3000L 36KW/steam 7.5 0-63 15 2930
DFM-5000L 48KW/steam 11 0-63 22 2940
customizable customizable customizable customizable customizable customizable

Operation Principle

movable high shear mixer Homogenizer mixer Emulsifier,quickly and evenly disperse a phase or phases to another consecutive phase,usually,these phases are dissolvable to each other.The rotor revolves quickly and strong force is produced through high tangent speed and high frequency mechanical effect,therefore,the material in the narrow slotamong stator and rotor receives strong forces from mechanical and liquid shearing,centrifugal force,pressing,liquid fraction,clashing,tearing and rush water.The dissolvable solid,liquid and gas material is then instantly dispersed and emulsified evenly and finely with better production procedures and appropriate addictives and finally products with stable high quality are made.
Stainless Steel Portable Agitator Mixer Cosmetic High Shear Homogenizer Pneumatic Lifting

Working Process

The rotor revolves in high speed produces centrifugal force,which suctions the material from upper and lower feeding area axially to the operation chamber.The strong centrifugal force throws the material axially to the narrow slot between stator and rotor.The material then receives centrifugal press,clash and other forces,which firstly disperse and emulsify the material. The outer terminal of the rotor revolved in high speed produces a line speed more.than 15m/s and even up to 40m/s,which produces strong mechanical and liquid shearing,liquid abrasion,clashing and tearing which fully disperse,emulsify,homogon.and break the material and jet from the stator slot.As materials jet in radial in high speed,they change their flow direction with resistance from themselves and vessel walls.The upperand lower axial suction force then leads to strong upper and lower rushing flows.After many circulations,the material is finally disper sed and emulsified evenly.
