Carrot Pomace Sanitary Rotary Valve 500x500mm SKF Bearing
Carrot Pomace Sanitary Rotary Valve 500x500mm SKF Bearing
Carrot Pomace Sanitary Rotary Valve 500x500mm SKF Bearing
Carrot Pomace Sanitary Rotary Valve 500x500mm SKF Bearing
Specifications
Brand Name :
CHEEGERS
Model Number :
RV-D.V-90L
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
USD250~7900/unit
Payment Terms :
T/T, D/P, D/A, L/C, Western Union, MoneyGram
Supply Ability :
200units per month
Delivery Time :
40-45 days
Packaging Details :
Plywood
Name :
Rotary Discharge Valve
Model :
RV-D.V-90L
Output :
8-50tons/hr
Flange Size :
500X500mm
Clearance :
0.08-0.2mm
Bearing :
SKF & others
Blade :
8
Motor :
Standard or as customer needs
Power :
3kw, 4kw
Description

Rotary Discharge Valve For Carrot Pomace Dosing From Discharge Screw Conveyor
Product Introduction

Name Rotary Discharge Valve For Carrot Pomace Dosing From Screw Conveyor
Model RV-D.V-90L
Conveying material Powder and granule, particle
Volume/rotation 90L/hr
Capacity( m³ ) 2 T/h-- 200 T/ h &others
Rotor speed(r/min) 20-50
Rotor vane 8
Temperature(°C) <400°
Clearance ≥0.06mm
Material Stainless steel
Bearing High temperature resistant bearing
Out-bearing New type out-bearing
Motor SEW & others
Power(kw) 4kw
Drive arrangement Straight connected / Chain drive
Voltage 380V 415V & others
Color whitebluegreen & others
Advantage

Smooth surface,long service life,low noise,clog-free,easy

installation and remove, precision finishing process.

Application

Silo emptying, dosing, batching, mixing,pneumatic conveying applications,

conveyor feeding / unloading, screw feeder feeding,etc.


Carrot Pomace Sanitary Rotary Valve 500x500mm SKF Bearing
Carrot Pomace Sanitary Rotary Valve 500x500mm SKF Bearing

Carrot Pomace Sanitary Rotary Valve 500x500mm SKF Bearing
Dimension Display of Rotary Airlock Feeder
Carrot Pomace Sanitary Rotary Valve 500x500mm SKF Bearing

Type Inlet outlet Size
C D H h A B E F Φ Power
TGFZ-5L 150 150 400 200 250 250 105 105 250 1.1kw
TGFZ-7L 200 200 440 220 300 300 130 130 250 1.1kw
TGFZ-9L 250 250 440 220 350 350 155 155 250 1.1kw
TGFZ-12L 300 300 440 220 400 400 180 180 250 1.5kw
TGFZ-20L 300 300 460 230 400 400 180 180 300 1.5kw
TGFZ-30L 350 350 520 260 450 450 204 204 350 2.2kw















Overseas Exhibitions

Cheegers has been engaged in exhibitions home and abroad for some time, like Thailand, Turkey, Iran, Pakistan, etc.

We supply rotary valves for many brands in China, like Buhler, Sataka, Cofco, Yihai Kerry, Muyang, etc.

Carrot Pomace Sanitary Rotary Valve 500x500mm SKF Bearing

Carrot Pomace Sanitary Rotary Valve 500x500mm SKF Bearing

Compamy Profile

Chengdu Cheegers Machinery Limited Company is committed to researching and manufacturing rotary valve, diverter valve, slide gate valve and magnet separator used in bulk solids conveying over half a century, having accumulated rich experience in design and producing. Cheegers gains a good reputation in maket home and abroad. In China, we have cooperation with Buhler, Cofco, Sinograin, Yihai Kerry, Sataka and so on. Overseas, our valves are exported to more than, 30 countries, like Thailand, Korea, Malaysia, Phillipine, Australia, Singapore, America, the Uk, Canada, Dubai, Saudi Arabia, etc.
Carrot Pomace Sanitary Rotary Valve 500x500mm SKF Bearing
Factory Overview
For every production step our workers are carefully finished. QC department is strictly following the quality standard by 100% inspection for all the products. Cheegers never stop studying,researching and developing new designs on rotary valves. Each year, we will launch new designs which suit different application conditions.
Carrot Pomace Sanitary Rotary Valve 500x500mm SKF Bearing

Certificate

Cheegers has got the CE for Rotary discharge valve and diverter valve as below:

We also have other patents for rotary valve and diverter valve domestically.

Like high airtight rotary airlock valve patent, apprearance patent for airlock valves, etc
