High Temperature Calcining Lime Rotary Kiln For Construction Works
High Temperature Calcining Lime Rotary Kiln For Construction Works
High Temperature Calcining Lime Rotary Kiln For Construction Works
High Temperature Calcining Lime Rotary Kiln For Construction Works
High Temperature Calcining Lime Rotary Kiln For Construction Works
High Temperature Calcining Lime Rotary Kiln For Construction Works
Specifications
Brand Name :
ZHONGKE
Certification :
ISO CE
Place of Origin :
Henan, China
MOQ :
1 set
Price :
$66,000.00 - $780,000.00 / Set
Supply Ability :
100 Set/Sets per Month
Product name :
Limestone Calcined Machine
Applicable Industries :
Manufacturing Plant, Construction works , Energy & Mining
Core Components :
PLC, engine, Bearing, Gearbox, MOTOR, GEAR
After-sales Service Provided :
Online support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support
Power(W) :
800-20000KW
Weight :
10t-2000t, 237 tons, 30-300t
Dimension(L*W*H) :
According to the type
Pre-heater :
Vertical Pre-heater
Keyword :
China Rotary Kiln
Core Components Warranty :
3 years
Description

High Temperature Calcining Rotary Kiln Lime Rotary Kiln

Introduction of Rotary Lime Kiln

Rotary kiln cement plant is the main equipment for claiming cement clinker and it can be used widely for cement industry, metallurgy industry, chemical industry, etc.

Rotary kiln cement plant is composed of the shell, the supporting device, the supporting device with thrust roller, the driving device, the movable kiln head, the sealing device at kiln tail, the combustion device, etc.

Rotary kiln cement plant has the simple structure and reliable operation, at the same the production process of the rotary kiln can be controlled easily.

Through the technical renovations, the rotary kiln claiming system equipment has adopted the advanced hydraulic thrust roller device,and the other national advanced technologies.

Working Principle Of Rotary Lime Kiln

According to the applicable materials, it can be divided into cement rotary kiln, lime kiln, ceramic sand rotary kiln, metal magnesium rotary kiln, bauxite kiln etc.The rotary kiln is composed of barrel, supporting device, catch wheel supporting device, transmission device, movable kiln head, kiln tail sealing device, and coal injection pipe device

Features of Rotary Lime Kiln

Rotary kiln cement plant is used for calcinating high standard cement in cement factories, but also widely used in metallurgy, construction and chemical industry.

The rotary kiln produced by our factory has strong structure, smooth operation, and high quality products. Besides, we provide our customers with advanced and efficient shaft preheater and five stage cyclone preheater.


Main Technical Parameters:

Design Capacity(t/d) 150 300 600
Product Active Lime Active Lime Active Lime
preheater Vertical Pre-heater Vertical Pre-heater Vertical Pre-heater
rotary kiln size (m) Φ2.5×40 Φ3.3×50 Φ4×60
Effective Volum (m3) 142 292 575
Burning temperature ≤1250 ≤1250 ≤1250
cooler Grate Cooler Grate Cooler Grate Cooler
fuel Gas
Coal Dust		 Gas
Coal Dust		 Gas
Coal Dust
Heat Consumption(kJ/kgCao) 5000-5300 5000-5300 5100


Parameter of lime stone kiln rotary:

size (m) Φ2.5×40 φ2.8x42 Φ3x46 Φ3.2x50 φ3.2x54 φ3.6x56 φ3.8x58 Φ4x60 Φ4.3x58 Φ4.3x64 Φ4.8x68
Effective
Volume (m3)		 142 190 235 292 390 430 505 575 670 738 1005
Burning
temperature
(°C)		 1350/1250 1350/1250 1350/1250 1350/1250 1350 1350 1350 1350 1350 1350 1350
capacity (t/d) 150 200 250 300 350 400 500 600 750 800 1000

High Temperature Calcining Lime Rotary Kiln For Construction Works

other product:

Magnesium oxide rotary kiln

Lime rotary kiln

Cement rotary kiln

Chemical rotary kiln

High Temperature Calcining Lime Rotary Kiln For Construction Works

FAQ

Q1: How long is the warranty of the rotary kiln?
A1: Our warranty period is one year generally.
Q2: How long shall we replace the refractory brick?
A2:Usually 6-12 months(Depends on the time and temperature.)
Q3: Can l visit your factory?
A3:Yes. We warmly welcome you to visit our factory.We will take you to our customer site to have a real look.We will arrange a car to pick you up at the Xinzheng International Airport.
Q4: Do you provide equipment operation training?
A4:Yes.We can send professional engineers to the working site for installation, adjustment, and operation training. All of our engineers have passports.
Q5: Do you provide whole rotary kiln flow chart?
A5:Yes. Our experienced engineers are specialized in designing process flow for various project, such as cement production line, quick lime production line,magnesium production line etc.
Q6: Can you test our samples?
A6:Yes.You can send your samples to us for test and analysis.
Q7:How about price?
A7.Yes, we are factory and are able to give you the lowest price than market one and we have a policy that “for saving time and absolutely honest business attitude, we quote as low as possible for any customer, and discount can be given according to quantity.contact us.
