Capsule Slip Rings with Through Hole 30 Circuit
Capsule Slip Rings with Through Hole 30 Circuit
Capsule Slip Rings with Through Hole 30 Circuit
Capsule Slip Rings with Through Hole 30 Circuit
Capsule Slip Rings with Through Hole 30 Circuit
Capsule Slip Rings with Through Hole 30 Circuit
Specifications
Brand Name :
JINPAT
Model Number :
LPC-30T
Certification :
ISO9001.ISO14000.CE.UL.FCC.RoHS
Place of Origin :
China
MOQ :
1PCS
Price :
Negotiable
Payment Terms :
TT/CC/Paypal
Delivery Time :
2 weeks ARO
Packaging Details :
Standard/On Request
Supply Ability :
50K units/week
Operating Speed :
0-300 rpm
Circuits :
30
Contact Material :
Gold to Gold
Lead Length :
Standard 250 mm (9.843inch)
Electrical Noise :
1mΩMin
Application :
medical equipment.
Insulation Resistance :
100 MΩ @ 500 VDC
Description

Through-Hole High-Speed Slip Ring with Gold-Gold Contacts and Low Electrical Noise for CCTV Equipment

LPC-30T Capsule Slip Ring Description

Slip ring can be used in any electromechanical system that requires unrestrained, continuous rotation while transferring power or data from a stationary to a rotating structure. It is also called a rotary electrical interface, commutator, collector, swivel or an electrical rotary joint. It can improve electromechanical capability, simplify system design, eliminate possible damage while rotation.

The LPC-30T capsule slip ring is a standard, off-the-shelf unit that uses gold contacts at the rotary interface. Color-coded lead wires are used on both the stator and rotor for simplifying electrical connections. Contact part adopts rare metal and solid gold plating process, the slip ring of long wear-resisting and antioxidant properties, and ensure the slip ring long service life effectively.

Using a 90° V-groove ring design for each ring, the LPC-30T provides smoother running, lower torque and lower electrical noise than competitive slip rings.

Product Model of Applied Case

Specifications
Operating Speed 0-200 rpm
Number of Circuits 30
Voltage 240 VAC/DC
Current Rating 2 amps per circuit
Temperature Range -20℃ to +60℃
Contact Material Gold to Gold
Lead Size 28# silver plated copper
Lead Length Standard 250 mm (9.843inch)
Hole Diameter 1.5~7.0mm
Dielectric Strength ≥500 VAC @50Hz, between each circuit
Insulation Resistance 100 MΩ @ 500 VDC
Electrical Noise 1mΩ Min

Capsule Length =L
# of Circuits L (mm) Part No
30 62.3 LPC-30T

Application picture

Capsule Slip Rings with Through Hole 30 Circuit
