Precious Metal Separate Slip Ring 12 Circuits Jinpat Electronics One-stop slip ring solution

JINPAT slip ring of LPS series have been applied to the vehicle. It consists of separate rotor and brush, of which the rotor part is able to come with a through hole to install the shaft for customers. Such a rotary electrical interface is able to transmit combination of weak signals with low resistance. Furthermore, the stator connecting way is optional ranging from wielding pin to wielding copper ear, wielding wire and shape from circular to semi-arc, superimposed, to screw fixed ones. Apart from a 360° rotating transmission, the rotating speed can run up to 2000 rpm. Applied to the drone, the part can achieve an efficient maneuvering of unmanned aircrafts in a high speed of rotation and the function of quick capture of pictures. Moreover, with a high precision and reliable performance, it improves the high definition of images and easy transition of the drone. Typical products include LPS-06A/B, LPS-12A/12B models. They have been applied successfully to UAV system for aerial photography.

Features

• 12 circuits models
• Speed up to 300 rpm continuous
• Gold-Gold contacts
• 250mm standard lead length
• Compatible with data bus protocols
• Sealed units are available
• Flexible, color-coded, silver-plated, ead wires
• Precision ball bearings meet or exceed life requirements for most commercial applications

Advantage

• Low torque minimizes system torque budget
• Compact design to fit in the most demanding space.
• Smooth running
• Low electrical noise
• Quick shipment per your urgent requirement
• 360°continuous rotation
• High bandwidth transfer capability

Main Application

• Electrical test equipment
• Manufacturing and process control equipment
• Indexing tables
• CCTV pan / tilt camera mounts
• Robotics, rotary sensors, urgent illumination equipment
• Exhibit/display equipment
• Medical equipment
• Aviation, military, instrument
• Mini-type wire-rolling machine
• Custom Machinery
• OEM Machinery
