Miniature Slip Ring 6 Circuit Custom Solutions Available
Miniature Slip Ring 6 Circuit Custom Solutions Available
Specifications
Brand Name :
JINPAT
Model Number :
LPM-06B
Certification :
ISO9001.ISO14000.CE.UL.FCC.RoHS
Place of Origin :
China
MOQ :
1PCS
Price :
Negotiable
Payment Terms :
TT/CC/Paypal
Supply Ability :
50K units/week
Delivery Time :
2 weeks ARO
Packaging Details :
Standard/On Request
Number of Circuits :
6
Voltage :
240 VAC/DC
Contact Material :
Gold to Gold
Other Application :
CCTV pan
One Application :
Total Station
Two Application :
Robotics Slip Rings
lead length :
Standard 250 mm (9.843inch)
Description

High Performance 240 VAC Miniature Slip Ring Custom Solutions Available, Mass Production​

The LPC-06B slip ring capsule is a standard, off-the-shelf unit that uses gold contacts at the rotary interface. Color-coded lead wires are used on both the stator and rotor for simplifying electrical connections.

Using a 90° V-groove ring design for each ring, the LPC-06B provides smoother running, lower torque and lower electrical noise than competitive slip rings. It is available in1- 6 circuit models.

Electronic & Electruc Mechanical
Circuits Total 6CKT Working Speed 0~300rpm
Detail

6X1A(You can go through 2A

under certain circumstances )

 Contact Material Gold to Gold
Rating Voltage 110VAC/DC Housing Material Engineering plastics
Dielectric Strength

≥200VAC@50Hz(P)

≥100VAC@50Hz(S)

 Lead Wire Length

Stator: 250士5mm

Rotor: 250士5mm
Insulation Resistance

≥500MΩ@200VDC(P)

≥10MΩ@100VDC(S)

Dynamic Resistance

Fluctuation Balue

 ≤35mΩ
35mEnvironment Remarks
Working Temperature -20°C~+60° Application /
Working Humidity ≤60%RH Other /
IP IP40 Note:"P" stands dor power, "S" stands for signal

Outline Drawing

Miniature Slip Ring 6 Circuit Custom Solutions Available

Description

LPM-06B slip rings are small and compact with capsule length 18.2mm with capsule style, standard, off-the-shelf.

Color-coded lead wires are used on both the stator and rotor for simplified electrical connections.

Using a 90° V-groove ring design for each ring.

These slip rings are manufactured by utilizing premium grade metal-alloys using the edge-cutting technologies with the help of our deft team members. The offered slip rings are assembled in varied mechanical components to increase the rate of power transmission.

The family of these compact sling ring capsules permits enormous versatility in dealing with the size requirements of systems when there are no bigger models available.
