Coupling Driven Twin Screw Air Compressor Rotorcomp Stable Running
Coupling Driven Twin Screw Air Compressor Rotorcomp Stable Running
Coupling Driven Twin Screw Air Compressor Rotorcomp Stable Running
Coupling Driven Twin Screw Air Compressor Rotorcomp Stable Running
Coupling Driven Twin Screw Air Compressor Rotorcomp Stable Running
Coupling Driven Twin Screw Air Compressor Rotorcomp Stable Running
Specifications
Brand Name :
Shanghai Rotorcomp
Model Number :
LGCD screw compressor
Certification :
ISO.TUV,CE,GS
Place of Origin :
Germany
MOQ :
Min.:1set
Price :
Negotiable
Payment Terms :
Western Union, T/T, L/C, D/P, D/A
Supply Ability :
3,000 sets/per month
Delivery Time :
15-20 working days
Packaging Details :
Exported Wooden Package
Warranty :
2 Years
Air Rotors :
Made in Germany
Advanced Design :
Design in Germany
cooling system :
Enlarged air cooling system than 20-25% with better performance
Rated Power :
200Kw/300Hp
driving system :
Coupling
Service coefficient :
1.2
Dimension :
2650*1650*1850mm
Weight :
3600Kg
Lubricating oil volume :
140L
Certificates :
ISO,TUV,CE
Description

Twin Screw Direct Driven Rotary Screw Air Compressor 200KW in TUV,CE,ISO certificates in better price!

Advantages of LGCD Direct Driven Screw Compressor:

1. Coupling driving system
2. Highly competitive price
3. Economic running costs
4. ISO, GA, SGS certificates

Twin Screw Direct Driven Rotary Screw Air Compressor features:

1 Drives and electrics

The almost loss-free power transmission guarantees reliable, high-performance compressor operation. The regular maintenance requirement is reduced to lubrication of the motor. All the electronic components are brand products of leading
manufacturers. rives and electrics.

Coupling Driven Twin Screw Air Compressor Rotorcomp Stable Running

2 Air end block – reliable centrepiece – Design in Germany

The centrepiece of Direct-driven Screw compressor is the air end, which is constructed and manufactured with the most modern production methods in China. The optimal air end for your compressor can be used on a modulating basis. In frequency-controlled units, where the operating pressure changes, adjustments can also be made on the frequency controller to optimally adjust the speed of the compressor to the compressor performance.

Coupling Driven Twin Screw Air Compressor Rotorcomp Stable Running

3 Electric motor

Only electric motors from well-known manufacturers of protection class IP54/IP23 are used in our Direct-driven Screw compressor. As a standard, the drive motors are monitored both thermally (via the thermistor of the motor) as well as electronically(overload protection via the frequency inverter).

Coupling Driven Twin Screw Air Compressor Rotorcomp Stable Running

4 Oil separation system

LGCD Direct-driven Screw compressor up to 132 kW are equipped with external separators that can be changed in a simple spin-off/spin-on process. Larger units have an internal separator cartridge. Due to the excellent separation efficiency of the system as a whole, the compressors can be used in the pressure range of 5.0 to 15.0 bar. Special pressures on request.

Coupling Driven Twin Screw Air Compressor Rotorcomp Stable Running

Frequency inverters (optional)

The frequency converter minimises idle times and optimises supply with fluctuating compressed air requirements. Start-up peaks are avoided and the compressor’s delivery rate is controlled continuously – that saves electricity costs! The total costs for your compressed air supply are significantly reduced and investment costs are amortised in the shortest possible time.

Coupling Driven Twin Screw Air Compressor Rotorcomp Stable Running

200KW air cooling compressor parameters

ITEM UNIT MODEL
LGCD-35/8 LGCD-30/10 LGCD-27/13
Discharge capacity m3/min 35 30 27
Working pressure MPa 0.8 1.0 1.3
Cooling style Air cooling
Working style one stage, continuous working
Driven method Direct driven
Inlet status Temperature ℃ ≤40
Pressure MPa Atmospheric pressure
Relative humidity ≤100%
Noise dB(A) ≤85
Oil content ppm ≤2
Drive rotor speed rpm 2972
Dust particle size μm 1μm
Cooler outlet temperature ℃ Ambient temperature＋10
Cooling air flow m3/min 880
Displacement control mode Load/empty + stop for too long empty status
Safety valve set pressure MPa 0.88 1.1 1.43
Lubricating oil volume L 140
Lubricating oil brand ROTORCOMP
Air outlet connection size DN80
Drain connection size G1
Dimension L mm 2650
W mm 1650
H mm 1850
Net Weight kg 3600
Motor Type Y2315L2-2
Rating rpm 2972
Power KW 200
Service coefficient 1.2
Degree of protection IP55
Insulation class F(B)
Startup mode Reduced voltage
Voltage V 380
Frequency Hz 50
Rated current A 348
Weight of motor kg 1170
Coupling Driven Twin Screw Air Compressor Rotorcomp Stable Running
Coupling Driven Twin Screw Air Compressor Rotorcomp Stable Running
