High Efficiency Portable Screw Compressor LGCD 22Kw Power TUV Certification
High Efficiency Portable Screw Compressor LGCD 22Kw Power TUV Certification
High Efficiency Portable Screw Compressor LGCD 22Kw Power TUV Certification
High Efficiency Portable Screw Compressor LGCD 22Kw Power TUV Certification
High Efficiency Portable Screw Compressor LGCD 22Kw Power TUV Certification
High Efficiency Portable Screw Compressor LGCD 22Kw Power TUV Certification
Specifications
Brand Name :
Shanghai Rotorcomp
Model Number :
LGCD screw compressor
Certification :
ISO.TUV,CE,GS
Place of Origin :
Germany
MOQ :
Min.:1set
Price :
Negotiable
Payment Terms :
Western Union, T/T, L/C, D/P, D/A
Supply Ability :
3,000 sets/per month
Delivery Time :
15-20 working days
Packaging Details :
Exported Wooden Package
Warranty :
2 Years
Air Rotors :
Made in Germany
Advanced Design :
Design in Germany
cooling system :
Enlarged air cooling system than 20-25% with better performance
Motor :
IP55 super high efficient motor
driving system :
Coupling
Contractor :
Schneider Brand
Controller :
Touchable colorful controller as option
Maintenance :
Simple&advanced design for low maintenance cost
Filter :
MANN brand
Valves :
HOERBIGER
Description

Electric Rotary Air Screw Compressor 22Kw TUV,CE,ISO certificates in cheaper price!

LGCD Direct-driven Electric Rotary Air Screw Compressor features:

The curved face of the rotors engaged fully, thus contributing to the formation of a hydrodynamic lubrication film, reducing the contact zone of the lateral leakage, improve compressor efficiency; as well as to improve the processing, test performance of the rotor.

Fully meet or exceed the national standard ISO19153-2003 air compressors energy efficiency limit !

Oil separation system

LGCD Direct-driven Screw compressor up to 132 kW are equipped with external separators that can be changed in a simple spin-off/spin-on process. Larger units have an internal separator cartridge. Due to the excellent separation efficiency of the system as a whole, the compressors can be used in the pressure range of 5.0 to 15.0 bar. Special pressures on request.

High Efficiency Portable Screw Compressor LGCD 22Kw Power TUV Certification

Frequency inverters (optional)

The frequency converter minimises idle times and optimises supply with fluctuating compressed air requirements. Start-up peaks are avoided and the compressor’s delivery rate is controlled continuously – that saves electricity costs! The total costs for your compressed air supply are significantly reduced and investment costs are amortised in the shortest possible time.

High Efficiency Portable Screw Compressor LGCD 22Kw Power TUV Certification

22KW /30HP air cooling compressor parameters

ITEM UNIT MODEL
LGCD-22
Free air delivery m3/min 3.65 3.60 3.20 2.75
Max. working pressure MPa 0.7 0.8 1.0 1.3
Compressor type Oil inject screw compressor
Cooling type Air cooling
Driven type Direct driven
Inlet status Temperature ℃ ≤45
Pressure MPa Atmospheric pressure
Relative humidity ≤90%
Noise Level dB(A) ≤72
Residual oil content ppm ≤2
Drive rotor speed rpm 2940 2940 2940 2940
Compressed air outlet temperature ℃ Ambient temperature＋10
Cooling air flow m3/hr 7800
Control mode Intelligent controller
Safety valve set pressure MPa 0.77 0.88 1.10 1.43
Lubricating oil volume L 15
Lubricating oil brand ROTORCOMP
Compressed air outlet connection G1
Dimension L mm 1310
W mm 850
H mm 1160
Net Weight kg 470
Motor Model Y2180M2-2
Speed rpm 2940
Rated Power KW 22
Service factor 1.2
Protection type IP23/IP55/IP54
Insulation class F
Startup mode ʏ-Δ starting
Voltage V 380(Special on request)
Frequency Hz 50(Special on request)
Rated current A 42.2
Weight of motor kg 173
High Efficiency Portable Screw Compressor LGCD 22Kw Power TUV Certification
High Efficiency Portable Screw Compressor LGCD 22Kw Power TUV Certification
