Easy Application Oil Injected Rotary Screw Air Compressor Rotorcomp Sizing Air Software
Easy Application Oil Injected Rotary Screw Air Compressor Rotorcomp Sizing Air Software
Specifications
Brand Name :
Shanghai Rotorcomp
Model Number :
LGFD-18.5
Certification :
ISO.TUV,CE,GS
Place of Origin :
GERMAN
MOQ :
negotiate
Price :
negotiate
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100-2000sets/Month
Delivery Time :
5-15 Working days
Packaging Details :
Plywood case for export package
Product Name :
Oil Injected Rotary Screw Air Compressor
Capacity(m3/min) :
10 bar 2.9
Power(kw) :
18.5
In/outlet :
G1
Noise :
71 dB
Dimension :
1250×960×1300 MM
Weight :
730 KG
Feature :
Long life cycle
Description

Easy Application Oil Injected Rotary Screw Air Compressor Rotorcomp Sizing Air Software

Advantages of our new EVO technology

1. New ROLLING PROFILE– ultimate efficiency with
reduced noise
2. Long life cycle due to increased bearing dimensions
and wear-free ROLLING PROFILE
3. Wide operating pressure range from 5 to 15 barg
Air end –
4. “Made in Germany”
5. Quality assurance – bench test of every air end
before leaving our factory
6. Easy application selection with our new
ROTORCOMP-SIZING AIR software
7. Highest flexibility for your package design
• Suitable for all types of drive driving motors
• Drive options: Belt drive, direct drive, internal
gear drive
• Base and face-flange mounting

About US

Shanghai Rotorcomp air compressor is an economic air compressor package, with the benefit of a heavy duty working design, low maintenance cost and internal components that are easy exchangeable. LGFD model is flexible for air cooled and water cooled industrial applications.
This series comes in a belt driven motor type (7.5 – 75kw) and a direct driven model (18.5 – 355kw), with working pressures from 7.5 to 13 bar(g), and with Free Air Delivery from 1.2 – 62 m3/min.

Features of Oil Injected Rotary Screw Air Compressor

  1. Compact and Simple Design
  2. Microprocessor Control Panel
  3. Superior Larger 5 : 6 Profile Airend Design
  4. Larger Cooler for High Ambient Temperature Area Operation
  5. IP55 High Efficiency Main Motor
  6. 1 : 1 Motor Belt/Direct Couple Airend Design
  7. VSD Inverter Control Standard Configuration Option

To achieve sustainable development

Extra low noise emission

Develop by Jersey North America Development Center--- low noise SKY air end
Heavy machinery design
Low-speed centrifugal fan and inverter oil cooling fan
Equipped with air intake Muffler

Energy conservation

Each set of air compressor meets national energy conservation standards
High efficient motor engine
Direct drive and no gear energy saving loss
Inverter oil cooling fan and suction cooling down
Germany suction valve

High reliability

World class R&D team---provide the powerful safeguard to product quality
"Rotorcomp" rotor line, cylinder bearing or taper-roller bearing integrative design, bearing lifespan >>100,000 hours
Five years warranty for main machine, two years warranty for motor and radiator
Patent air valve and patent cooler
Coolant and three filters imported from Germany
First class production process and inspection equipment, realize the designer’s philosophy perfectly

Parameter of

ModelCapacity(m3/min)*Power(kw)In/outletNoiseDimensionWeight
8bar10bar13bar15barMotorMotor(Fan)dB(A)**L×W×H in mmkg
LGFD-5.50.870.750.610.535.50.09G169900×750×900245
LGFD-7.51.21.040.90.87.50.09G169900×750×900250
LGFD-111.791.581.321.17110.18G170950×800×1290370
LGFD-152.42.151.841.66150.18G170950×800×1290480
LGFD-223.513.162.712.45220.37G1711250×960×1300750
LGFD-304.884.323.643.25300.75G1-1/4711440×1006×12961200
LGFD-457.086.35.434.94451.1G1-1/4751440×1006×12961400
LGFD-559.328.337.056.31551.1G2751600×1200×16501600
LGFD-7512.3111.139.618.74751.1G2751600×1200×16501750
LGFD-9016.4514.2611.7210.8902.2G2752000×1580×17902600
LGFD-13220.2617.4814.2513.051102.2G2782500×1700×19003000
LGFD-18023.0820.5417.6516.051322.2G2782500×1700×19003150
Note:
1. The above parameters and color are designed according to customer needs, the parameters are for reference only, the final parameters of the drawings shall prevail;
2. According to user requirements and needs, to join way: air/water cooling, oil content, weight, appearance size according to the need to design, to the final order and the technical agreement shall prevail;
  1. Frequency converters (optional).
  2. 2 years warranty, 5 years warranty for air end


Easy Application Oil Injected Rotary Screw Air Compressor Rotorcomp Sizing Air Software
