Taiwan doublenut ball screw,imported square guide rail , Cheap 4 Axis CNC Rotary Table Foam Cutting Machine
Taiwan doublenut ball screw,imported square guide rail , Cheap 4 Axis CNC Rotary Table Foam Cutting Machine
Specifications
Brand Name :
BLUE ELEPHANT
Model Number :
ELE1836
Certification :
CE, ISO9001，SGS，CIQ
Place of Origin :
Jinan City, Shandong Province,China
MOQ :
1set
Price :
9999-12999$
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200sets per Month
Delivery Time :
10-15working days
Packaging Details :
Standard marine export plywood case
Table Surface :
T-slot working Table
Frame :
Welded Steel Square Tube Structure
X, Y Structure :
Rack and Pinion Drive, Hiwin Rail Linear Bearings
Z Structure :
Hiwin Rail Linear Bearings and Ball Screw
Spindle Power :
6*3 kw water cooling spindle
Drive Motors :
Stepper system
Description

Taiwan doublenut ball screw,imported square guide rail , Cheap 4 Axis CNC Rotary Table Foam Cutting Machine

Specification

Description Parameter
model ELE-1836-6
Working area(X*Y*Z) 1800*3600*200mm( can be customized)
Max rapid moving speed 35000mm/min
Max carving speed 27000mm/min
Cutting accuracy ±0.03/300mm
Repositioning Accuracy ±0.03mm
Table Surface T-slot working Table
Frame Welded Steel Square Tube Structure
X, Y Structure Rack and Pinion Drive, Hiwin Rail Linear Bearings
Z Structure Hiwin Rail Linear Bearings and Ball Screw
Spindle Power 6*3 kw water cooling spindle
Spindle Speed 24000 rpm
Drive Motors Stepper system
Working Voltage AC380V/50/60Hz,3PH (Option: 220V)
Command Language G Code
Operating System NCstudio control System
Warranty 12 month
Software Compatibility Type3/UcancameV9 Software

1 . All machine heads can work at the same time,can also work alone,

good coherence and high quality when batch processing

2 . Is an economical processing machine

3 . Adopt Taiwan doublenut ball screw,imported square guide rail.

4 . Gantry movement,long time use no distortion

5 . Heads and working area can be changed according to client’s requests.

Applications

The wood products: wave board processing, wood door, folding screen, window, etc . assisted processing of various kinds of furniture products.

Advertising industry: ad signs, Logo making, acrylic cutting, HPL panels, the production of advertising decorative products.

Furniture: wooden doors, cabinets, office and wood furniture, computer table, panel furniture, office furniture, wooden speakers, other furniture processing, etc.

Other industries: Non-metallic mold industry, Poly dragon auto mould industry processing.

Processing materials: MDF board, wood, organic glass, PVC board, double color plate, copper, aluminum, marble, crystal.

Our Service

1, Within 7 days since your local customs clearance: if the cnc router’s any parts has any problems,

we will change it free.

2, Exceed 7 days since your local customs clearance but within warranty period: if the cnc router parts

have any problems, we can change the old machine parts to new ones free, but you should pay all

the shipping cost.

3, Exceed warranty period: if the cnc router parts have any problems, we can offer new machine parts

with cost price and you also should pay all the shipping cost.

4, We offer 24 hours technical support by call, and email.

5, Our technician can give you remote guide online(Skype or MSN) if you have any question.

6, We can record videos of operating the laser machine.

7, Free training course in our factory.

8.Machine will be adjusted before it is delivered , operation disk/CD was included.

Company Information

Jinan Blue Elephant CNC Equipment Co., Ltd is located in Jinan City , Shandong Province .

We have always been developing to the research and manufacturer of CNC router machine and laser

cutting engraving machine .

We have our R & D department , Quality control department , and after sale &service department .

Our products are widely used in Woodworking ,Advertising , Model ,Electric , CAD/CAM Industry model ,

Clothing , Package Printing , Marking , Laser sealing and so on .

We had got CE and FDA certification always offer best quality machine .

Our Philosophy : To Be First Brand -- CNC Manufacturer & wholesaler Platform !

Just looking forward to service every customer, like you .
