AC380V Headstone Engraving Equipment , Rock Etching Equipment Cast Steel Structure Frame
AC380V Headstone Engraving Equipment , Rock Etching Equipment Cast Steel Structure Frame
Specifications
Brand Name :
BLUE ELEPHANT
Model Number :
ELE1325
Certification :
CE, ISO9001, SGS, CIQ
Place of Origin :
Jinan City, Shandong Province,China
MOQ :
1set
Price :
9999-29999$
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200sets per Month
Delivery Time :
15-20working days
Packaging Details :
Standard marine export plywood case
Table Surface :
T-slot Table
Frame :
Cast steel Structure
X, Y Structure :
Rack and Pinion Drive, Hiwin Rail Linear Bearings
Z Structure :
Hiwin Rail Linear Bearings and Ball Screw
Drive Motors :
Stepper System
Operating System :
DSP System(Options: Ncstudio/Mach3 PC Software)
Description

China supplier High Speed cnc router machine ELE - 1325S Stone CNC Router with best price and service

Application:

Stone serious engraving machine is mainly used in the engraving of the hard materials such as marble,grantie,glass,stone ect.

Technical parameters:

NO. Description Parameter
1 X,Y,Z Working Area 1300x2500x200mm
2 X,Y,Z Traveling Positioning Accuracy ±0.03/300mm
3 X,Y,Z Repositioning Accuracy ±0.03mm
4 Table Surface T-slot Table
5 Frame Cast steel Structure
6 X, Y Structure Rack and Pinion Drive, Hiwin Rail Linear Bearings
7 Z Structure Hiwin Rail Linear Bearings and Ball Screw
8 Max. Power Consumption 3Kw
9 Max. Rapid Travel Rate 20000mm/min
10 Max. Working Speed 10000mm/min
11 Spindle Power 3KW water cooling spindle
12 Spindle Speed 0-24000RPM
13 Drive Motors Stepper System
14 Working Voltage AC380V/50/60Hz,3PH (Option: 220V)
15 Command Language G Code
16 Operating System DSP System (Options: Ncstudio/Mach3 PC Software)
17 Computer Interface USB
18 Flash Memory 128M(U Disk)
19 Collet ER20
20 X,Y Resolution <0.01mm
21 Software Compatibility Type3/UcancameV9 Software, (Option: Artcam Software)
22 Running Environment Temperature 0 - 45 Centigrade
23 Relative Humidity 30% - 75%

After-sale service:


1 , Within 7 days since your local customs clearance: if the cnc machine’s

any parts has any problems, we will change it free.
2 , Exceed 7 days since your local customs clearance but within warranty

period: if the cnc machine parts have any problems, we can change the old

machine parts to new ones free, but you should pay all the shipping cost.
3 , Exceed warranty period: if the cnc machine parts have any problems, we

can offer new machine parts with cost price and you also should pay all the shipping cost.
4 , We offer 24 hours technical support by call, email
5 , Our technician can give you remote guide online(Skype or MSN) if you have any question
6 , We can record videos of operating the laser machine
7 , Free training course in our factory
8 . Machine will be adjusted before it is delivered , operation disk/CD was included.
