Benchtop CNC Router Machine For Plastic Sign Making Stepping Motor & Driver
Benchtop CNC Router Machine For Plastic Sign Making Stepping Motor & Driver
Specifications
Brand Name :
BLUE ELEPHANT
Model Number :
ELE2030
Certification :
CE, ISO9001，SGS，CIQ
Place of Origin :
Jinan City, Shandong Province, China
MOQ :
1 set
Price :
US $4,999 - 9,999 / Set
Payment Terms :
L/C, D/A, D/P, Western Union, MoneyGram, T/T
Supply Ability :
200 Set/Sets per Month
Delivery Time :
10-15 working days
Packaging Details :
Standard marine export plywood case
Voltage: :
AC380V/50/60Hz,3PH (Option: 220V)
Dimension(L*W*H): :
3200X2100X1980mm
Control system: :
Ncstudio 63A
Inverter: :
5.5kw Fuling Inverter
Spindle power: :
5.5KW ATC water cooling spindle
Transmission: :
Taiwan TBI Ball Screw
Guide rail: :
20# Hiwin Square Guide Rail
Spindle Speed: :
0-24000RPM
Drive motor: :
Stepper
Description

ELE 2030 china cnc machine , ATC wood cnc machine for plastic sign making

Features:

  • Working area: 2000mm*3000mm *200mm
  • Steel gantry , strong structure
  • T-slot & vacuum working table
  • 5.5KW Changsheng ATC water cooling spindle
  • 5.5kw Fuling inverter
  • Z axis with Taiwan TBI Ball screw transmission
  • X,Y axis with high precision helical rack gear transmission
  • X,Y,Z axis with Taiwan TBI/PMI/HIWIN Linear Guide
  • Original Ncstudio 63A controller
  • Stepping motor & Driver
  • Double motors for Y axis
  • Oil lubrication system
  • Artcam /Type 3 software
  • Voltage:380V, 3phase, 50/60HZ

.

Main parts

Benchtop CNC Router Machine For Plastic Sign Making Stepping Motor & Driver

Technical Parameters

Number Description Parameter
1 X,Y,Z Working Area 2000x3000x200mm
3 X,Y,Z Traveling Positioning Accuracy ±0.03/300mm
4 X,Y,Z Repositioning Accuracy ±0.03mm
5 Table Surface Vacuum & T-slot Table
6 Spindle 5.5kw Changsheng ATC water cooling spindle
7 X, Y Structure 20#Taiwan HIWIN Linear guide and helical rack
8 Z Structure Ball screw and#20 Taiwan HIWIN Linear guide
9 Driver and Motor Stepper
10 Max. Rapid Travel Rate 45000mm/min
11 Max. Working Speed 30000mm/min
12 Software Artcam /Type 3 software
13 Spindle Speed 0-24000RPM
14 Lubrication system Manual
15 Inverter 5.5kw Fuling Inverter
16 Command Language G Code
17 Control System Ncstudio 63A
18 Computer Interface USB
19 Flash Memory 512M(U Disk)
20 Collet ER25
21 X,Y Resolution <0.01mm
22 Software Compatibility Type3 Software, (Option: Artcam Software)
23 Running Environment Temperature 0 - 45 Centigrade
24 Relative Humidity 30% - 75%

Application

1. WoodFurniture Industry: Wave Plate, fine pattern, antique furniture, wooden door, screen,

craft sash, composite gates, cupboard doors, interior doors, sofa legs, headboards and so on.

2. Advertising industry: advertising identification, sigh making, Acrylic engraving and cutting,

crystal word making, blaster molding, and other advertising materials derivatives making.

3. die industry: A sculpture of copper, aluminum, iron and other metal molds, as well as

artificial marble, sand, plastic sheeting, PVC pipe, wooden planks and other non-metallic mold.

4. relief sculpture and 3D engraving

Packaging and shipping

1. Outside Package:Standard export wooden case .

2. Inner package:strech film .
For shipping,you can choose the sea shipping,air shipping or the transmission of expressage:DHL/TNT/Fedex.

For terms of payment,you can choose the EXW/FOB/CIF/DDP/DDU.It depends on what you would like better.
