1325 Three Processes Multi Head CNC Router Machinery with HQD Air Cooling Spindle
1325 Three Processes Multi Head CNC Router Machinery with HQD Air Cooling Spindle
1325 Three Processes Multi Head CNC Router Machinery with HQD Air Cooling Spindle
1325 Three Processes Multi Head CNC Router Machinery with HQD Air Cooling Spindle
1325 Three Processes Multi Head CNC Router Machinery with HQD Air Cooling Spindle
1325 Three Processes Multi Head CNC Router Machinery with HQD Air Cooling Spindle
1325 Three Processes Multi Head CNC Router Machinery with HQD Air Cooling Spindle
1325 Three Processes Multi Head CNC Router Machinery with HQD Air Cooling Spindle
1325 Three Processes Multi Head CNC Router Machinery with HQD Air Cooling Spindle
1325 Three Processes Multi Head CNC Router Machinery with HQD Air Cooling Spindle
Specifications
Brand Name :
BLUE ELEPHANT
Model Number :
ELECNC- 1325
Certification :
CE, ISO9001, SGS, CIQ
Place of Origin :
Jinan City, Shandong Province, China
MOQ :
1 set
Price :
US $13,000 - 29,999 / Set
Payment Terms :
D/A, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200 Set/Sets per Month
Delivery Time :
10-20 working days
Packaging Details :
Standard marine export plywood case
X,Y,Z Working Area :
1300x2500x200mm
Table Surface :
T-slot & vacuum working Table
X, Y Structure :
china #25 linear guide rail,helical rack gear
Z Structure :
Taiwan TBI Ball Screw
Taiwan TBI Ball Screw :
Taiwan TBI Ball Screw
Drive Motors :
750W leadshine Servo Motor&driver
Working Voltage :
AC220V/50/60Hz,3PH (Option: 380V)
Command Language :
G Code
Operating System :
SYNTEC control system
Software Compatibility :
Type3/UcancameV9 Software
Description

1325 Three Processes Multi Head CNC Router Machinery with HQD Air Cooling Spindle

1325 Three Processes Multi Head CNC Router Machinery with HQD Air Cooling Spindle

Features:

  • Three spindle working one by one,non-synchronous type multi head cnc router,more convenient to change the tool to processing wooden crafts of different shapes.
  • The machine spindle is China HQD spindle.It’s more economic and good performance.
  • New type thicker and bigger heavy duty welded frame and gantry.

Parameters:

Description

Parameter

X,Y,Z Working Area

1300x2500x200mm

Table Surface

T-slot & vacuum working Table

X, Y Structure

china #25 linear guide rail,helical rack gear

Z Structure

Taiwan TBI Ball Screw

Spindle Power

6kw HQD Air Cooling Spindle*3

Drive Motors

750W leadshine Servo Motor&driver

Working Voltage

AC220V/50/60Hz,3PH (Option: 380V)

Command Language

G Code

Operating System

SYNTEC control system

Collet

ER32

X,Y Resolution

<0.01mm

Software Compatibility

Type3/UcancameV9 Software

Running Environment Temperature

0 – 45 Centigrade

PS:All the working area and specifications can be customized according to your requests.

1325 Three Processes Multi Head CNC Router Machinery with HQD Air Cooling Spindle
1325 Three Processes Multi Head CNC Router Machinery with HQD Air Cooling Spindle
1325 Three Processes Multi Head CNC Router Machinery with HQD Air Cooling Spindle
1325 Three Processes Multi Head CNC Router Machinery with HQD Air Cooling Spindle
1325 Three Processes Multi Head CNC Router Machinery with HQD Air Cooling Spindle
1325 Three Processes Multi Head CNC Router Machinery with HQD Air Cooling Spindle
1325 Three Processes Multi Head CNC Router Machinery with HQD Air Cooling Spindle

Packaging & Delivery
Packaging Details: 1.Outside package:Standard marine export plywood case.
2.inner package:Stretch film and plastic film for humidity.
We can package according to your requests.
Delivery Detail: Shipped in 15 working days after payment.

1325 Three Processes Multi Head CNC Router Machinery with HQD Air Cooling Spindle


Our Factory
1325 Three Processes Multi Head CNC Router Machinery with HQD Air Cooling Spindle
Jinan Blue Elephant CNC Machinery Co., Ltd is located in Jinan City, Shandong Province. We have always been developed to the research and manufacturer of CNC router machine and laser cutting engraving machine.
We have our R & D department, Quality control department, and after sale & service department.
Our products are widely used in Woodworking, Advertising, Model, Electric, CAD/CAM Industry model, Clothing, Package Printing, Marking, Laser sealing and so on.
We had got CE and ISO9001 certification always offer best quality machine.
Our Philosophy: To Be First Brand -- CNC Manufacturer & wholesaler Platform!
Just looking forward to service every customer, like you.
1325 Three Processes Multi Head CNC Router Machinery with HQD Air Cooling Spindle
