1000LPH Brackish Water System / Treatment , RO Water Treatment System For Drinking Water
1000LPH Brackish Water System / Treatment , RO Water Treatment System For Drinking Water
1000LPH Brackish Water System / Treatment , RO Water Treatment System For Drinking Water
1000LPH Brackish Water System / Treatment , RO Water Treatment System For Drinking Water
Specifications
Brand Name :
Kaiyuan
Model Number :
KYRO-500LPH
Certification :
ISO9001, CE, SGS
Place of Origin :
Guangzhou, China
MOQ :
>= 1sets
Price :
negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
>300sets/month
Delivery Time :
1-7working days(depand on raw materials stocking)
Packaging Details :
export standard wooden case(plywood), no need to fumigate, suitable for shipping.
RO Membrane :
USA DOW
Production Capacity :
500liters per hour
Recovery Rate :
40%
Electrical Power :
220/380V 50/60Hz
Tank Material :
FRP
Control Valve :
Automatic/ Manual
Pipe fitting :
SUS304/ U-PVC
Warranty :
1 Year
Size :
1870*650*1850MM
Feed Water TDS :
≤20000mg/L
Description

1000LPH Brackish water treatment/ drink water treatment machine/ ro water treatment system

1.Product Description

Large and medium-sized sea water, sub-sea water and brackish water desalination equipment for high salt and alkali areas and sea water intrusion, island and other regions, the company research and development production of large and medium-sized desalination equipment using reverse osmosis desalination system and supporting high-quality desalination components, Post-taste improvement and PH value adjustment system with reasonable pretreatment equipment, can effectively remove inorganic salts, heavy metal ions, organic matter. bacteria and bacteria and other harmful ingredients. the sea water, sub-sea water. brackish water desalination in line with national Drinking water standard quality water. According to the customer's local water quality for detailed analysis and special design. and strive to be efficient and durable. and make the desalination of water quality fully meet the national standard of drinking water quality(gb5749-2006) completely solve the problem of drinking water in dry areas.

2.Product Details

kyro-500lph RO Water Purifier Machine:
1. Capacity: 5000L/H
2. Rated power: 2.5KW/H
3. Voltage: 110V/220V/380V, 50Hz/60Hz, single phase/3phase
4. Desalting rate:>=97%
5. Water recovery rate: 40%
6. TDS of raw water: ≤20000μs
7. TDS of pure water: ≤600μs

Optional Components:

A. Regulating wheels

B. PC Touch Screen
C. Two-stage RO system
D. PH adjustment
E. CIP cleaning system
F. Auto or manual control valve
G. U-PVC or stainless steel pipe
H. UV sterilizer/Ozone Generator
I. Dosing system(anti-scale)/Water Softener
J. PE or stainless steel raw/pure water tank
K. FRP or stainless steel pre-treatment tank

3.Product Processing

The basic process of equipment.


Brackish water from the water pump into the quartz sand (multi-media filter) and activated carbon filtration system filtration. Filtered water after water quality reduction, PH adjustment and scale inhibitor added after the access to the precision and security filtration system, filtered low pressure brackish water all the way into the high-pressure pump pressure, the other way into the pressure exchange energy recovery device, after pressurized pump pressurized with high pressure pump into the reverse osmosis membrane reactor system. High-pressure brackish water in the membrane reactor under the treatment of the formation of fresh water through the membrane after water quality adjustment into the fresh water tank storage. The rest of the high pressure concentrated water enters the pressure exchange energy recovery unit to recover the energy after discharge.

4. Application

1)Equipment for islands, ships, fishing, coastal water shortages
2)The rack is made of rust-proof and corrosion-resistant material
3) Large-scale equipment using energy recovery device to reduce the system running energy consumption small and micro-equipment using multi-stage desalination device to reduce the operating pressure of the system to reduce the size of equipment to facilitate the miniaturization of equipment.
4)Power: 220V/50/60HZ, 380V/50/60HZ (can also be customized according to customer requirements of different voltage).
5)fresh water quality in line with national drinking water quality standards(gb5749-2006)
6)Design life of 10 years
7)Another can be customized container type desalination equipment system
