Two Stage SS 500LPH Water Treatment Plant RO System
Two Stage SS 500LPH Water Treatment Plant RO System
Two Stage SS 500LPH Water Treatment Plant RO System
Two Stage SS 500LPH Water Treatment Plant RO System
Two Stage SS 500LPH Water Treatment Plant RO System
Two Stage SS 500LPH Water Treatment Plant RO System
Specifications
Brand Name :
Kaiyuan
Model Number :
KYRO-500LPH
Certification :
ISO9001, CE, SGS
Place of Origin :
Guangzhou, China
MOQ :
>= 1sets
Price :
negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
>300sets/month
Delivery Time :
1-7working days(depand on raw materials stocking)
Packaging Details :
export standard wooden case(plywood), no need to fumigate, suitable for shipping.
Name :
Water Treatment Plant RO System
Production Capacity :
500liters per hour
Recovery Rate :
50% - 75%
Electrical Power :
220V / 380V 50Hz / 60Hz
Tank Material :
SS
Control Valve :
Automatic/ Manual
Pipe fitting :
SUS304/ U-PVC
Stage :
Two Stage
Description

Two Stage SS 500LPH Water Treatment Plant RO System

1. Water Treatment Plant RO System Features

All stainless steel 304 / 316L material.

Regular pre-treatment with crystal sand filter and activated carbon filter.

Dow reverse osmosis(RO) membranes

Automatic controlling system.

Product water quality monitor.

Automatic self-protection system.

Automatic flushing system.

2. Water Treatment Plant RO System Details

kyro-500lph Water Treatment Plant RO System

Capacity

500L/H

Water recovery

more than 50%

Function

Producing Fresh Water

Type

Pure Water Treatment System

Application

Filtration

Material

FRP+PVC/stainless teel

Usage

Pure Water Process

Voltage

110V / 220V / 380V

Desalting rate

more than 97%

Membrane

USA Filmtec DOW

3. Water Treatment Plant RO System Processing

Process: raw water tank→ raw water pump→quartz sand filter →activated carbon filter→water softener/chemical dosing system(optional)→security filter→high pressure pump→ro system→pure water tank+UV sterilizer(ozone generator) +precision filter+ water supply point

First stage pretreatment.(Sand filter)

The use of multi-medium quartz sand filters, main purpose is to remove the water contains sediment, manganese, rust, colloid material, mechanical impurities, suspended solids and other particles in the above 20UM of substances hazardous to health.

Second stage pretreatment (Carbon filter)

Activated carbon filters used to remove the pigment in the water, smell, a large number of chemical and biological organisms, reducing the residual value of water and pesticide pollution and other harmful pollutants.

Third stage pretreatment (Resin softener)

Cationic resin used for water softening, primarily to remove hardness of water. So as to effectively prevent the reverse osmosis membrane fouling. System can automatically recoil, and so is red.

Fourth stage pretreatment (Micron filter)

Particle size in water to remove fine particles, sand filters can remove very small colloidal particles in the water, so that the turbidity reached 1 degree.

RO system

The core equipment of water pump is imported and the membrane film is imported from Hydranautics in America. It is equipped with full set of clean unit. It has the features of simple structure, convenient operation and high technological level.

4. Water Treatment Plant RO System Application

1. Dairy, Fruit Juice, Vegetable Juice And Other Clear, Concentrated.

2. Animals And Plants (Aloe Vera, Mangosteen, Tea, Etc.) Effective Ingredients Extraction.

3. Soybean Protein, Oligosaccharides, Isoflavones And Other Extraction, Concentration.

4. Antibiotics, Amino Acids, Vc And Other Fermentation Broth Purification, Concentration.

5. Chinese Medicine (Bupleurum, Salvia, Scutellaria, Etc.) Injection Of Active Ingredients Purification, Separation.

5. Water Treatment Plant RO System Optional Components


UV sterilizer
Water Softener
Ozone Generator
Two-stage RO system
Regulating wheels
Dosing system
Automatic cleaning system
PE,stainless steel or FRP water tank

Two Stage SS 500LPH Water Treatment Plant RO System
