High Flow Drinking Water Treatment Plant , Industrial Reverse Osmosis Water System
High Flow Drinking Water Treatment Plant , Industrial Reverse Osmosis Water System
High Flow Drinking Water Treatment Plant , Industrial Reverse Osmosis Water System
High Flow Drinking Water Treatment Plant , Industrial Reverse Osmosis Water System
High Flow Drinking Water Treatment Plant , Industrial Reverse Osmosis Water System
High Flow Drinking Water Treatment Plant , Industrial Reverse Osmosis Water System
Specifications
Brand Name :
Kaiyuan
Model Number :
KYRO-500LPH
Certification :
ISO9001, CE, SGS
Place of Origin :
Guangzhou, China
MOQ :
>= 1sets
Price :
negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
>300sets/month
Delivery Time :
1-7working days(depand on raw materials stocking)
Packaging Details :
export standard wooden case(plywood), no need to fumigate, suitable for shipping.
ype :
Drinking Water Treatment Plant
Production Capacity :
500LPH
Recovery Rate :
50% - 75%
Type :
Reverse Osmosis Water System
Tank Material :
FRP / Stainless Steel / Carbon Steel
Feature :
High Flow
Pipe fitting :
SUS304 / SUS316L / U-PVC
Operating temperature :
5℃ - 39℃
Description

High Flow Drinking Water Treatment Plant , Industrial Reverse Osmosis Water System

Drinking Water Treatment Plant Introduction ?

Reverse Osmosis Water System is raw water through precision filter, granular activated carbon filters, activated carbon filters, compression, and then through the pump pressure, the use of reverse osmosis membrane pore size 1/10000μm make a higher concentration of water into low concentration of water, while the industrial pollutants, heavy metals, bacteria, viruses and other impurities in the water mixed with a large number of full isolation, to achieve the required physical and chemical indicators for drinking and hygiene standards, outputs to clean pure water is the best choice of body replenish water quality. It is key equipment of pure water plant.


Drinking Water Treatment Plant Details

kyro-500lph Reverse Osmosis Water System

1. Capacity: 500L/H

2. Rated power: 1.5KW/H

3. RO System Rack Size: 1650*630*1800mm

4. Desalting rate:>=97%

5. Water recovery rate: 50-75%

6. TDS of raw water: ≤ 2000PPM

7. TDS of pure water: ≤ 60PPM

8. Voltage: 110V / 220V / 380V, 50Hz / 60Hz, single phase / 3phase

Drinking Water Treatment Plant Component

There are several kinds of consumables you need to replace regularly.
a. Quartz sand: replaced about every 15 months. 50kg/bag
b. Activated carbon: replaced about every 15 months. 25kg/bag
c. Resin: replaced about every 15 months. 25L/bag
d. PP Filter cartridge: replaced about every 1 month

Drinking Water Treatment Plant Optional Components

A. Regulating wheels
B. PC Touch Screen
C. Two-stage RO system
D. PH adjustment
E. CIP cleaning system
F. Auto or manual control valve
G. U-PVC or stainless steel pipe
H. UV sterilizer/Ozone Generator
I. Dosing system(anti-scale)/Water Softener
J. PE or stainless steel raw/pure water tank
K. FRP or stainless steel pre-treatment tank

Drinking Water Treatment Plant Details

High Flow Drinking Water Treatment Plant , Industrial Reverse Osmosis Water System
High Flow Drinking Water Treatment Plant , Industrial Reverse Osmosis Water System
High Flow Drinking Water Treatment Plant , Industrial Reverse Osmosis Water System
