Specifications
Brand Name :
Kaiyuan
Model Number :
KYRO- 500LPH
Certification :
ISO9001, CE, SGS
Place of Origin :
Guangzhou, China
MOQ :
negotiation
Price :
negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
>300sets/month
Delivery Time :
1-7working days(depand on raw materials stocking)
Packaging Details :
export standard wooden case(plywood), no need to fumigate, suitable for shipping.
Name :
Ro Water Purifier Machine
Production Capacity :
500liters per hour
Recovery Rate :
50% - 75%
Application :
Filtration
Tank Material :
FRP/ Stainless Steel/ Carbon Steel
Other Name :
Drinking Water Treatment Systems
Pipe fitting :
SUS304/ U-PVC
Warranty :
1 Year
Description

500 LPH Water Well Drilling Water Purifier Ultrapure Water Purification System

Ro Water Purifier MachineDescription

Ro Water Purifier Machine is using city water as raw water, then treat water by Pre-filter (water softener is optional), reverse osmosis membrane. It can remove particle, colloid, organic impurity, heavy metal ion, bacteria, virus in water, and it can also remove 99% dissolved salt. The whole system desalination rate can reach 96%-99% to make permeated water conductivity<10 us/cm. Dense water also won't polluted environment.

EDI is also known as electrodeionization, is a new type of ultra pure water producing technology which gradually developed in the 20th Century, It is a revolutionary progress in the history of pure water production technology. This technology is skillfully combined electroosmosis technology with ion exchange technology. By means of the selectivity permeation effect on anion and cation by the anion and cation exchange membrane, and exchange effect on ion by ion exchange resin. Under direct-current electric field, realize the directed migration of ions, thus completely make water salt removing, meanwhile, hydrogen ion and hydroxyl ion generated by water electrodeionization will make the ion exchange resin regeneration, so it can produce ultrapure water continuously without acid-base chemical regeneration.

Ro Water Purifier Machine Details

Model
KYRO-500LPH 2 stage
Production capacity
500 Liters per hour
Total power
About 4.0KW
Raw water pump
SS304 1 set Nanfang
Quartz sand filter, carbon filter
Automatic control vlave, SS304
one stage Security filter
20″×5μm , 3cores , SS304
one stage High-pressure pump
SS304 1 set CNP
one stage RO membrane
Membrane LCLE-4040 3 PCS USA DOW
Two stage High-pressure pump
SS304 1 set CNP
Two stage RO membrane
Membrane LCLE-4040 2pcs USA DOW
Membrane housing
4040 5pcs , SS304
Feed water
less than 2000 ppm
1 stage RO system desalination rate TDS
less than 60 ppm
2stage RO system desalination rate TDS
less than 2 ppm
EDI system desalination rate TDS
less than 0.1 ppm
Warranty
One year
Payment
T/T or West union(30% deposit in advance,70% blance pay before delivery)

Ro Water Purifier Machine Processing

Process: raw water tank→ raw water pump→quartz sand filter →activated carbon filter→water softener/chemical dosing system(optional)→security filter→high pressure pump→ro system→pure water tank+UV sterilizer(ozone generator) +precision filter+ water supply point

CWater Well Drilling Water Purifier Machine Ultrapure Water Purification System

Ro Water Purifier Machine Advantages:

1.Can run and produce water continuously, highly automatic


2.No need chemical to regeneration,easy operation and maintainance

3.RO system uses imported USA DOW membrane

4.Automatic switch on when lack of water,and switch off when no water or full of water

5.RO membrane auto wash and reduce the pollution speed.

6.Low-pressure switch protects high-pressure pump from damage cause by water supply stops.

7.Production water conductivity meter monitors water quality online continuosly.


8.Input water and dense water pressure meters, monitor the RO differential pressure and remind the time of washing.
RO Water Treatment Plant Optional Components :


A. Regulating wheels
B. PC Touch Screen
C. Two-stage RO system
D. PH adjustment
E. CIP cleaning system
F. Auto or manual control valve
G. U-PVC or stainless steel pipe
H. UV sterilizer/Ozone Generator
I. Dosing system(anti-scale)/Water Softener
J. PE or stainless steel raw/pure water tank
K. FRP or stainless steel pre-treatment tank

Ro Water Purifier Machine Details

CWater Well Drilling Water Purifier Machine Ultrapure Water Purification SystemCWater Well Drilling Water Purifier Machine Ultrapure Water Purification System

Thank you so much for your value time. Any questions please send us inquiry or chat now!
We will reply you within 24hours. Whatsapp/ wechat/ tell: +86 13711203110

Guidelines for getting a proper quotation
Tell us the raw water/source of water
Provide water analysis report
Required production capacity( 500 liters per hour, 1000liters per hour…)
What's the pure water used for( drinking, bottle water or industrial use…)
