12TPH Salt Water Filtering Plant Water Filters Reverse Osmosis Plant With Ozonator
12TPH Salt Water Filtering Plant Water Filters Reverse Osmosis Plant With Ozonator
12TPH Salt Water Filtering Plant Water Filters Reverse Osmosis Plant With Ozonator
12TPH Salt Water Filtering Plant Water Filters Reverse Osmosis Plant With Ozonator
12TPH Salt Water Filtering Plant Water Filters Reverse Osmosis Plant With Ozonator
12TPH Salt Water Filtering Plant Water Filters Reverse Osmosis Plant With Ozonator
12TPH Salt Water Filtering Plant Water Filters Reverse Osmosis Plant With Ozonator
12TPH Salt Water Filtering Plant Water Filters Reverse Osmosis Plant With Ozonator
Specifications
Brand Name :
Kaiyuan
Model Number :
KYRO-12000LPH
Certification :
ISO9001, CE, SGS
Place of Origin :
Guangzhou, China
MOQ :
negotiation
Price :
negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
>300sets/month
Delivery Time :
1-7working days(depand on raw materials stocking)
Packaging Details :
export standard wooden case(plywood), no need to fumigate, suitable for shipping.
Name :
RO Water Device
Production Capacity :
12000liters per hour
Recovery Rate :
50% - 75%
Application :
Filtration
Tank Material :
FRP/ Stainless Steel/ Carbon Steel
Other Name :
Drinking Water Treatment Systems
Pipe fitting :
SUS304/ U-PVC
Warranty :
1 Year
Description

12TPH Planta Filtrado De Agua Salada Agua Filtros Planta Osmosis Inversa Planta Purificadora De Agua Con Ozonizador

Ro Water Purifier MachineDescription

Reverse osmosis process uses semi permeable spiral wound membranes to separate and remove dissolved solids,organic, pyrogens, sub micron colloidal matter and bacteria from water. Feed water isdelivered under a pressure of approximately 16 kg/cm2 through reverse osmosis membranes. Waterpermeates the minute pores of the membrane and is delivered as purified water. Impurities in the water are concentrated in the reject stream and flushed to drain. Reverse osmosis is capable of removing 90-99% of total dissolved solids (TDS), 99% of organic, including pyrogens, and 99%bacterials in the feed water.

Raw water: Well water, rains,river water, lake water,city water...

Output water: Human consumption water,bottled selling water,pharmaceutical industrial...

12TPH Salt Water Filtering Plant Water Filters Reverse Osmosis Plant With Ozonator

Ro Water Purifier Machine Details

Capacity

12000lph

Water recovery

more than 50%

Function

Producing Fresh Water

Type

Pure Water Treatment System

Application

Filtration

Material

FRP+PVC/stainless teel

Usage

Pure Water Process

Voltage

110V / 220V / 380V

Desalting rate

more than 97%

Membrane

USA Filmtec DOW

Ro Water Purifier Machine Processing

12TPH Salt Water Filtering Plant Water Filters Reverse Osmosis Plant With Ozonator

Process: raw water tank→ raw water pump→quartz sand filter →activated carbon filter→water softener/chemical dosing system(optional)→security filter→high pressure pump→ro system→pure water tank+UV sterilizer(ozone generator) +precision filter+ water supply point

Ro system technical parameters(for raw/well feed water TDS max 20000ppm)
Item Name
Brand
Material
Function
Raw Water Pump
CNP/Grundfos/Danfoss
SUS-304/316
Provide pressure for filters
Quartz Sand Filter
KaiYuan
FRP/ Ss-304/316
Filtrate sediments...
Activated Carbon Filter
KaiYuan
FRP/ Ss-304/316
Obsorb odor, smell, color, irons, chlorine... to make clear water
Anti-scalant chemical dosing system/Water Softener
SEKO
Soften water, protect RO Membranes
Security filter
KaiYuan
FRP/ Ss-304/316
Remove colloids larger than 5micro
High pressure pump
CNP/Grundfos/Danfoss
SUS-304/316
Provide pressure for Ro membranes
RO vessels &membranes
Domestic&DOW/Toray/Votron/Hydrau.
FRP/Ss-304/316
Remove dissolved ions,organic materia,bateria...
Solenoid valves, gauges,switch...
China
Cooper/Ss-304/316
To protect the machine underoperation
CIP Washing system(optional)
KaiYuan
Ss-304/ FRP/316
Membranes maitenance
Electronic control
PLC Program control system
Water quality detector,AC contacter,Air switch,indicator light,knob switch,electrical miscellaneous pieces...
UV/Ozone(optional)
USA/Dahuang
Remove some baterial like coliform,pseudomonas aeruginosa...(Sterilization)

Ro Water Purifier Machine Features:

1. Electronic industry: Pre-filter for ultra pure water, chemical products and pure water

2. Food and beverage industry: filter for mineral water, wines and fruit juice

3. Medicine industry: filter for drug liquid, gases

4. Chemical industry: filter for organic solvent

5. Petroleum industry: filter for oil-field flooding
6.Input water and dense water pressure meters, monitor the RO differential pressure and remind the time of washing.

Ro Water Purifier Machine Details

12TPH Salt Water Filtering Plant Water Filters Reverse Osmosis Plant With Ozonator

12TPH Salt Water Filtering Plant Water Filters Reverse Osmosis Plant With Ozonator

Thank you so much for your value time. Any questions please send us inquiry or chat now!
We will reply you within 24hours. Whatsapp/ wechat/ tell: +86 13711203110

Guidelines for getting a proper quotation
Tell us the raw water/source of water
Provide water analysis report
Required production capacity( 500 liters per hour, 1000liters per hour…)
What's the pure water used for( drinking, bottle water or industrial use…)
