Roll To Roll Web Aluminum Vacuum Metallizer, PVD R2R Sputtering Coating Machine,
Roll To Roll Web Aluminum Vacuum Metallizer, PVD R2R Sputtering Coating Machine,
Roll To Roll Web Aluminum Vacuum Metallizer, PVD R2R Sputtering Coating Machine,
Roll To Roll Web Aluminum Vacuum Metallizer, PVD R2R Sputtering Coating Machine,
Roll To Roll Web Aluminum Vacuum Metallizer, PVD R2R Sputtering Coating Machine,
Roll To Roll Web Aluminum Vacuum Metallizer, PVD R2R Sputtering Coating Machine,
Roll To Roll Web Aluminum Vacuum Metallizer, PVD R2R Sputtering Coating Machine,
Roll To Roll Web Aluminum Vacuum Metallizer, PVD R2R Sputtering Coating Machine,
Roll To Roll Web Aluminum Vacuum Metallizer, PVD R2R Sputtering Coating Machine,
Roll To Roll Web Aluminum Vacuum Metallizer, PVD R2R Sputtering Coating Machine,
Specifications
Brand Name :
ROYAL
Model Number :
RT-R2R
Certification :
CE
Place of Origin :
Made in China
MOQ :
1 set
Price :
negotiable
Payment Terms :
L/C, T/T, D/A, D/P
Supply Ability :
3 sets per month
Delivery Time :
16 weeks
Packaging Details :
Export standard, to be packed in new cases/cartons, suitable for long-distance ocean/air and inland transportation.
Chamber :
Horizontal orientation,
Material :
Stainless Steel 304/316
Technology :
Sputtering, Evaporation, Plasma Treatment
Application :
Electronic Paper, ITO Film, Flexible Circuits, Photovoltaic, Medical Strips And RFID.
Operation & Control :
Intuitive PLC And IPC Control.
Service & Training :
Available, From The USA Engineer And Technicians
Factory Location :
Shanghai city, China
Worldwide Service :
Poland - Europe; Iran- West Asia & Middle East, Turkey, India, Mexico- South America
Training Service :
Machine operation, maintenance, coating process Recipes, program
Warranty :
Limited warranty 1 year for free, whole life for machine
OEM & ODM :
available, we support tailor made design and fabrication
Description

R2R_web aluminum vacuum metallizer.pdf please download the E-catalogue

Roll To Roll Web Aluminum Vacuum Metallizer, PVD R2R Sputtering Coating Machine,

Flexible Circuits RFID Film Vacuum Web Coating Evaporation + Sputtering Web Roll to Roll Coater

Web Roll to Roll Vacuum Coater Features: with multiple deposition sources, available for oxide conducting film, metal conducting film, optical film, dielectric film.

Web Roll to Roll Vacuum Coater Substrates: PET,PEN, PES, PI, PC, PA films

Web Roll to Roll Vacuum Coater Applications: electronic paper, flexible circuits, photovoltaic, medical strips, RFID (Radio Frequency Identification) and Low-E film.

Web Roll to Roll Vacuum Coater Advantages


A. One chamber divided into multi-pressure zones to accommodate various deposition sources.
B. Multi-Source simultaneous deposition capabilities in one web pass, for multi-layer coating.
C. Reversible web winding direction enables deposition of unlimited layers without breaking vacuum.
D. Precision web handling mechanisms with edge-guide to allow multiple passes without loss of alignment. (Optional)
E. AC Invert web drive system for accurate control of multiple web speeds.
F. In-line optical and/or resistance thickness monitoring systems, to control precise deposition thickness and uniformity. (Optional)
G. Chamber is constructed of SUS304L Stainless with low out gassing components to insure deeper vacuum.

H. Vacuum pumping by a combination of turbo-molecular pump and low temperature cryogenics, to provide clean vacuum without moisture or oil contamination.

Please contact us for more specifications, Royal Technology is honored to provide you total coating solutions.
