250T 650*650mm Rubber Shoe Sole Making Machine Vulcanizing Tile Molding Machine
250T 650*650mm Rubber Shoe Sole Making Machine Vulcanizing Tile Molding Machine
250T 650*650mm Rubber Shoe Sole Making Machine Vulcanizing Tile Molding Machine
250T 650*650mm Rubber Shoe Sole Making Machine Vulcanizing Tile Molding Machine
250T 650*650mm Rubber Shoe Sole Making Machine Vulcanizing Tile Molding Machine
250T 650*650mm Rubber Shoe Sole Making Machine Vulcanizing Tile Molding Machine
250T 650*650mm Rubber Shoe Sole Making Machine Vulcanizing Tile Molding Machine
250T 650*650mm Rubber Shoe Sole Making Machine Vulcanizing Tile Molding Machine
250T 650*650mm Rubber Shoe Sole Making Machine Vulcanizing Tile Molding Machine
250T 650*650mm Rubber Shoe Sole Making Machine Vulcanizing Tile Molding Machine
Specifications
Brand Name :
HHS
Model Number :
XLB100-300
Certification :
CE
Place of Origin :
Qingdao Shangdong
MOQ :
1 set
Price :
USD 4000-10000
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
60 sets/Year
Delivery Time :
15-30 work days
Packaging Details :
standard wood package or based on clients request
Type :
Vulcanizer
Colour :
blue white,customized
Voltage :
customized
Power(W) :
5.5KW
Temperature :
300 degree
Working Layers :
1-4layers
Plates :
300-2100mm
Hot Plates Material :
Q-235 material.
Heating :
electricity , steam heating , conduction oil heating .
Weight :
2000 kg
advantage :
high production
Description

Best Price Rubber Shoe Sole Making Machine/Rubber Tile Vulcanizing And Moulding Machinery

1. Product Application

Conveyor belt vulcanizer, also called conveyor belt vulcanizing press or belt vulcanizing press machine. It's vulcanize equipment and tools for repairing & splicing of conveyor belt. It suits for various conveyor belt, such as EP, Rubber, Nylon, Canvas and Steel cord belt, etc.
The belt vulcanizer is dependable, lightweight and portable machine, which is widely used in the field of metallurgy, mining, power plants, ports, building materials, cement, coal mine, chemical industry, etc. Heating plates are available for rhombic, rectangular and modular type (two or more sets of heating plates together).

Universal column type vulcanizing machine

This machine is the main device which is used for pressing and forming various rubber model and non-model products. It can also be used for pressing various thermosetting plastic products. It has independent drive mechanism and electrical system, adopts button to centralized control. Working pressure and heating temperature can be adjust in the range.

It has the function of automatic pressure retrieve and oil pump stops overtime system. Circuit configuration is more reasonable and reliable.

Heating temperature, vulcanizing time, vulcanizing pressure, hydraulic pressure compensation can be set according to your need, easy to operate.

Hydraulic cylinder adopts to independent oil cylinder structure, easy to exchange. Piston adopts chilled cast iron, high wearable and long time use.

User can configure and select machine type according to the characteristic of products.

2. Product Paramenters

odel
XLB-650X650
XLB-600X600
XLB-700X700
XLB-800X800/1000
Clamping force
250T
300T
350T
500T
Max system pressure
21MPA
21MPA
21MPA
21MPA
Stroke
300mm
300mm
300mm
300mm
Rapid clamping speed
60mm/s
60mm/s
60mm/s
60mm/s
Plate size
650*650mm
600*600mm
700*700mm
700*700mm
800*800mm
1000*850mm
Daylight
300mm
300mm
300mm
300mm
Working layer
customized
customized
customized
customized
Max temperature
300C
300C
300C
300C
Motor
7.5kw
7.5kw
11kw
13kw
Control
PLC+HIM
PLC+HIM
PLC+HIM
PLC+HIM
Model
XLB-50T
XLB-100T
XLB-150T
XLB-200T
Clamping force
50t
100T
150T
200T
Max system pressure
21Mpa
21Mpa
21Mpa
21Mpa
Stroke
250mm
250mm
300mm
300mm
Rapid clamping speed
60mm/s
60mm/s
60mm/s
60mm/s
Plate size
380*380mm
400/400mm
400*400mm
450*450mm
500*500mm
500*500mm
510*540mm
600*550mm
Daylight
350mm
350mm
350mm
350mm
Working layer
customized
customized
customized
customized
Max temperature
300C
300C
300C
300C
Motor
3kw
4kw
5kw
7.5 kw
control
