Electric Steam Rubber Shoes Vulcanizing Tank Industrial High Pressure
Electric Steam Rubber Shoes Vulcanizing Tank Industrial High Pressure
Electric Steam Rubber Shoes Vulcanizing Tank Industrial High Pressure
Electric Steam Rubber Shoes Vulcanizing Tank Industrial High Pressure
Electric Steam Rubber Shoes Vulcanizing Tank Industrial High Pressure
Electric Steam Rubber Shoes Vulcanizing Tank Industrial High Pressure
Electric Steam Rubber Shoes Vulcanizing Tank Industrial High Pressure
Electric Steam Rubber Shoes Vulcanizing Tank Industrial High Pressure
Electric Steam Rubber Shoes Vulcanizing Tank Industrial High Pressure
Electric Steam Rubber Shoes Vulcanizing Tank Industrial High Pressure
Specifications
Brand Name :
HHS
Model Number :
DN0509
Certification :
ASME CE, ASME CE
Place of Origin :
Shandong, China
MOQ :
1 set
Price :
USD:8000-78000 /SET
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100 sets/month
Delivery Time :
20 working days
Packaging Details :
wood package /20-40 container
Max Working Press :
0.65MPa
Warranty :
1 years
Core Components :
PLC, Pressure vessel
Color :
Customer's Requirements
Advantage :
full automatic
Key Selling Points :
Easy to Operate
Voltage :
220V/380V/450V
Dimension(L*W*H) :
3200*2200*2300MM
Weight :
64000 KG
Curing time :
2.6~3h
Power :
110 kW
Temperature :
95~120℃
Description

production application

Rubber vulcanization is a chemical process at a given pressure, temperature and time for converting natural rubber into more durable materials by the addition of sulfur. These additives modify the polymer by forming cross-links (bridges) between individual polymer chains. Vulcanized materials are less sticky and have superior mechanical properties. And vulcanization autoclave is used widely for this chemical process.Electric Steam Rubber Shoes Vulcanizing Tank Industrial High Pressure

Widely used in vulcanization of rubber products, SBR thermoplastic as well as the carbonization and degreasing of bamboo, such as, rubber, cable, printing and dyeing, chemical, building materials and other industries. Mainly used in rubber products, rubber hose, rubber roller etc.It aslo can be used in the university laboratory for teaching and research.

Electric Steam Rubber Shoes Vulcanizing Tank Industrial High Pressure

Parameters

Model NO.
Diameter
Length
Capacity
Thickness
Design Temp
Design Pre
EDL1.2-3A.2
1200mm
3000mm
3.4CBM
8mm
190C
0.85MPa
EDL1.5-4A.2
1500mm
4000mm
7.06CBM
8mm
190C
0.85MPa
EDL1.5-6A.2
1500mm
6000mm
10.5CBM
8mm
190C
0.85MPa

Brand and Material of Major Components

No. item material
1 dished head carbon steel Q345R
2 tank carbon steel Q345R
3 flange forged carbon steel
4 safety interlocking device (pressure automatic)
5 track carbon or stainless steel
6 manual door opening device
7 saddle carbon steel Q235B
8 High temperature and high pressure fan ventilator air or water cooling
9 thermal insulation head carbon steel Q235B
10 Insulation material (double layer) aluminum silicate cotton
