Specifications
Brand Name :
HHS
Model Number :
XLB800-2200
Certification :
CE
Place of Origin :
Qingdao Shangdong
MOQ :
1 set
Price :
USD 50000
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
60 sets/Year
Delivery Time :
15-30 work days
Packaging Details :
Wooden cases / Containers, etc
Type :
Vulcanizer
Colour :
all colour
Voltage :
customized
Power(W) :
11KW*2
Temperature :
max 300 degree
Plates :
300-2100mm
Hot Plates Material :
Q-235 material.
Heating :
electricity , steam heating , conduction oil heating .
Weight :
50000 kg
Description

Rubber Car Mat Molding Machine/Rubber Conveyor Belt Vulcanizing Press/Plate Vulcanizing Press

1. Product Application

about our products:

1. Easy operation and repair

2. The vulcanizing machine is mainly use to produce rubber pads, Each working layer equipped with two sets moulds, it can take turn vulcanization. Thereby improve production efficiency
3. the center distance in certain, allowed to install large diameter of hydraulic cylinder, which can reduce the hydraulic cylinder the amount, and the simple structure, maintenance is less.

4. the beam in the section of force is reasonable, the modulus needed than live in small, can reduce weight

5. manufacturing installation is simple, pipe configuration, whole hidden appearance tidy and beautiful. Box type flat-band plate vulcanizing machine single box board the lateral stiffness ratio of the poor, but because the mast frame type flat-band plate vulcanizing machine frame by frame board are a combination of multiple, so the machine has enough lateral stiffness.

2. Product Paramenters

Model
XLB-800*800
XLB-1000*1000
XLB-1200*1200
mold closing force
160 ton
200 ton
250 ton
plate size
800*800mm
1000*1000mm
1200*1200mm
quantity of cylinder
1 set
1 set
1 set
piston diameter
300mm
380mm
380mm
working layer
1
1
1
daylight
300mm
300mm
300mm
unit area pressure
2.5 Mpa
2.0Mpa
1.8Mpa
Main motor
3 kw
5.5 kw
8 kw
machine weight
about 4000 kg
about 5800kg
about 6
