Mooney Viscometer Rubber Rheometer Rubber Rheometer Mooney Viscometer

Standards: ASTM-D2084,ASTM-D5289,ISO-6502, ASTM-D1646

Technical parameter:

Introduction:

Rubber rotor rheometer Measurement of vulcanization characteristics,

requirements, ISO6502 requirements and Italian standards require T10, T30, T50, T60, T90 data.

Feature:

1.the strong data function can support the drawing,storage

and output printing of multiple curves under the same interface.

2.it support the data query in many forms and output of excel queries and reports

3.it has many analysis function like statics, deviation setting,standards curve

setting ,and CPK statistical calculation

4.it has such function as interface query,local zoom and curve comparison.

5.selection of any any vulcanization time,range selection and screen capture.

6.analyzed the past test data once again,and increase or modify the reports,to

avoid the loss of data.

7.the test data are stored in the way of database,which is scientist

the multiple data sequencing ways are convince for data retrieval and query.

8.the machine will get the characteristic curve and data by measuring

the strength of rubber.

9.good reproducible and stasis tics.

Test Results

Measure of Mooney viscosity (Large rotor):

MI -- initial Mooney viscosity.

ML – The minimum Mooney value in the last 30 seconds before the motor stopped.

Mx-t - Mooney value relating to time t.

x-the time of preheat, t-Mooney test time

Stress Relaxation

MRe - Mooney value at the end of stress relaxation.

TRx - time needed for x% torque stress relaxation.

Xy% - % of Viscosity decay after motor stopped y sec.

The value of exponent a, the constant k, the correlation coefficient r, and the area A .

Graph ( with Viscosity-Time curve and Test temperature curve)

Mooney viscosity graph; Relaxation graph; log Mooney units Versus Log time graph.

Scorch Data testing sample results:

-Scorch time curve

-Temperature curve

-Curve index ( Input small or Large Rotor test

MI - initial Mooney viscosity

ML - Minimum Mooney viscosit

MF - Maximum Mooney viscosity in the end of the test

Mx-t - Mooney value relating to time t.

x-the time of preheat, t-Mooney test time

M5/M3 - ML+5/3 Mooney

M35/M18 - ML+35/18 Mooney

t5/t3 - Mooney burning time, M5/M3 corresponding time, Unit: min.

t35/t18 - Mooney vulcanizing time, ML+35/18 corresponding time, unit: min.

Standard Configure of MV-C3 Mooney Viscometer :

1 Machine Complete 1 Unit

2 O-ring 50 piece

3 Software operate 1 Unit

4 Large Rotor 1 Unit

5 Small Rotor 1 Unit

6 Warranty 1 Year(in China or free parts providing for out of Country)

7 Manual operator 1 Unit

Qingdao Honghesheng Industry Co., LTD, manufacturer of rubber machine,which is located in the west coast of Qingdao economic district, with 10 million registered capital. The company covers an area of 5000 square meters with 26 professional and technical staffs and 5 senior engineers. The technical staffs have working experience in large tire enterprise who can design more suitable equipment for the customer as for tire production process. Also they can provide new factory site planning and other services.
The company’s main products are: Rubber kneader, rubber mixing mill, rubber sheet cooling machine, inner tube production line,tyre production line, vulcanizing press, waste tyre recycling plant…
