Specifications
Brand Name :
HHS
Model Number :
HD-2-20
Certification :
ASME CE, ASME CE
Place of Origin :
Shandong, China
MOQ :
1 set
Price :
USD:5000-220000 /SET
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100 sets/month
Delivery Time :
20 working days
Packaging Details :
wood package /20-40 container
Max Working Press :
1.0 MPa
Warranty :
1 years
Core Components :
PLC, Pressure vessel
Color :
Customer's Requirements
Advantage :
full automatic
Key Selling Points :
Easy to Operate
Voltage :
380V/220V,for your optional
Dimension(L*W*H) :
6000MM*2500MM*2500MM
Weight :
11000KG
Work temperature :
150~200℃ curing temperature
Description

Hot Brander Of Electric Tire Retreading Hot Branding For Custom 8 Tires Retreading Line

Product Description

Used tire retreading machine / tire recycling machine / recycling machinery for waste tires is the main machine for cold tire retreading line, it can curing tread rubber on top of machine, and it can loading different tires size and number in one tank, can reach your different kind of requirements for tire retreading.

Used tire retreading machine / tire recycling machine / recycling machinery for waste tires work principle:

In high temperature and high pressure environment, the rubber is vulcanized and the whole vulcanization process is completed by using a new type of electric heating. The new stainless steel electrothermal tube sub-group N arranged in the tank wall, the high temperature fan through the temperature cycle plate to spread the heat from the back to the front evenly, pushed to the tank door, returned to the fan guide. Throughout the tank, the temperature is uniform and the pressure is constant, thus forming a working environment for tire vulcanization.

Technical Parameter:

Model HG-8
Capacity 8 tires/batch
Heating type Steam, electric, oil
Suitable for Car, truck, OTR tire
Size 4000*1800*2300mm

working process of the tyre retreading flow chart:

1.check out

Make sure the used tire casing can be accepted for retreading, or rejection.

2) Buffing

Buffing tire casing, buffing the worn tread rubber..

3) Planing

Remove all embedded objects in the casing, make sure the tire surface clean and solid, suitable for retreading.

4) Use glue gun

Use glue gun to spray a thin layer of concentrated liquid cement in the repair tire casings.

5) Glue filling
Fill in the repair cementing in the tire wound.

6) Apply the tread rubber

Apply the cushion gum between the tread rubber and the casing, as the bonding layer. As a new layer , the intensive precure tread rubber is forming in the tire casings

7) Assemble envelop

A special envelop is used to package the tires, ensure the tire casing and precure tread rubber successfully bond together

8) Curing

This is a process of applying the new tread rubber to the prepared tire casings, then put into curing chamber, in a certain pressure and temperature after a period of correct time curing, the cushion rubber layer will adhere tight to the tire casings.

9) Final inspection

Make sure all the recap been checked carefully, to ensure the safety and unharmed appearance of recycling products which sell to customers.

10) Everything looks "like new"

Now, end product! Safe and durable, is equally matched with the new tire. And ready to hit the road!

4. Optional production line

4pcs production line, 6pcs production line

8pcs production line, 10pcs production line

12pcs production line, 16pcs production line

20pcs production line, 24pcs production line, etc
