Natural Rubber Mat Platen Vulcanizing Press Hydraulic Hot Press Machine
Natural Rubber Mat Platen Vulcanizing Press Hydraulic Hot Press Machine
Natural Rubber Mat Platen Vulcanizing Press Hydraulic Hot Press Machine
Natural Rubber Mat Platen Vulcanizing Press Hydraulic Hot Press Machine
Natural Rubber Mat Platen Vulcanizing Press Hydraulic Hot Press Machine
Natural Rubber Mat Platen Vulcanizing Press Hydraulic Hot Press Machine
Natural Rubber Mat Platen Vulcanizing Press Hydraulic Hot Press Machine
Natural Rubber Mat Platen Vulcanizing Press Hydraulic Hot Press Machine
Natural Rubber Mat Platen Vulcanizing Press Hydraulic Hot Press Machine
Natural Rubber Mat Platen Vulcanizing Press Hydraulic Hot Press Machine
Specifications
Brand Name :
HHS
Model Number :
2000T
Certification :
CE
Place of Origin :
Qingdao Shangdong
MOQ :
1 set
Price :
USD 5000-150000
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
60 sets/Year
Delivery Time :
30 work days
Packaging Details :
standard wood package or based on clients request
Type :
Vulcanizer
Colour :
customized
Voltage :
customized
Heating plate :
2000*2000*85
Working Layers :
1layer
Clamping force :
20MN (2000tons)
advantage :
high production
Description

Natural Rubber Mat Press Machine / Platen Vulcanizing Press Rubber Machine / Hydraulic Hot Press Machine

1.Material of steel plate:

We use hight quality carbon steel Q-235(produce by Jigang Group Co.,Ltd which is a famous company) ,more thicker than other supplier,after shot blasting ,smooth, it is strong enough than common steel

2.Weldment of frame : world technique

Welded together as a whole part,Stewing fire treatment after weldment.

(Carbon dioxide gas shielded welding,alloyed welding wire).

Submerged arc welding, VSR treatment after weldment.

3.Piston:

The material of plunger is Chilled cast iron, after polishing,grinding treatment and resist compression test,make the surface smooth,anti-abrasion,durable.

4.Heating way&precision temperature control:

Steam ,oil or Electric (We use high quality hot platen and heating pipe to keep heating stability and uniformity) range of temperature:0-300°C (can be adjustment if you need 400 °C ,we can do it )

Plate temperature tolerance: ±0.1°C (very precise)other factory just is ±3°C

Also we can produce the machine with water cooling system.

5.Hydraulic system: (PLC control)

The professional hydraulic components, stable and reliable and quality .Pressure sensor control system pressure and never off pressure.

We use OMRON,SIMENS CHNT , SCHNEIDER ect brand electric parts.

6.There are more advanced technical information as our core patents,and not showed in the description,please send email to us.

Parameters/version

 XLB350*350*2 XLB400*400*2 XLB500*500*2 XLB600*600*2/4 XLB750*850*2 XLB1000*1000*2
Mould closing force 0.25MN 0.5MN 0.8MN 1.0MN 1.6MN 2.5MN
Hot plate spacing 125mm 125mm 125mm 125mm 125mm 200mm
Hot plate layer 2 2 2 2/4 2 2
Plunger stroke 250mm 250mm 250mm 250/500mm 250mm 400mm
Heating way Electricity/stream Electricity/stream Electricity/stream Electricity/stream Electricity/Stream Electricity/stream
Main motor power 2.2kw 2.2kw 2.2kw 2.2kw 3kw 5.5kw
The thermal power 2.4kw/board 3kw/board 3kw 7.5kw/board 9kw/board 10.8kw/board
Size(L*W*H)mm 1450*400*1350 1600*400*1440 1450*690*1818 1880*780*1660 2100*1010*1900 2400*960*2500
Weight(kg) 1200 1500 1700 2500/3100 3560/4300 8300


Detailed Images

Natural Rubber Mat Platen Vulcanizing Press Hydraulic Hot Press MachineNatural Rubber Mat Platen Vulcanizing Press Hydraulic Hot Press MachineNatural Rubber Mat Platen Vulcanizing Press Hydraulic Hot Press MachineNatural Rubber Mat Platen Vulcanizing Press Hydraulic Hot Press MachineNatural Rubber Mat Platen Vulcanizing Press Hydraulic Hot Press MachineNatural Rubber Mat Platen Vulcanizing Press Hydraulic Hot Press Machine

Natural Rubber Mat Platen Vulcanizing Press Hydraulic Hot Press Machine

Natural Rubber Mat Platen Vulcanizing Press Hydraulic Hot Press MachineNatural Rubber Mat Platen Vulcanizing Press Hydraulic Hot Press MachineNatural Rubber Mat Platen Vulcanizing Press Hydraulic Hot Press MachineNatural Rubber Mat Platen Vulcanizing Press Hydraulic Hot Press Machine
