Multifunction 7.5KW Three Roll Rubber Calender Machine XY-630
Multifunction 7.5KW Three Roll Rubber Calender Machine XY-630
Multifunction 7.5KW Three Roll Rubber Calender Machine XY-630
Multifunction 7.5KW Three Roll Rubber Calender Machine XY-630
Multifunction 7.5KW Three Roll Rubber Calender Machine XY-630
Multifunction 7.5KW Three Roll Rubber Calender Machine XY-630
Multifunction 7.5KW Three Roll Rubber Calender Machine XY-630
Multifunction 7.5KW Three Roll Rubber Calender Machine XY-630
Specifications
Brand Name :
SFC
Model Number :
XY-630
Certification :
CE/ ISO/ SGS
Place of Origin :
Qingdao
MOQ :
1 set
Price :
Negotiable
Supply Ability :
10 sets per Month
Delivery Time :
25 Working Days
Packaging Details :
Standard Wooden Case
Product Name :
3 Roller Calender
Roll Diameter :
230mm
Roll Length :
630mm
Motor Power :
7.5KW
Products Width :
100-500mm
Weight :
2600 kg
Description

XY-630 Three Roll Rubber Calendering Machine with Dependable Performance

Application:

Rubber calender is the basic equipment in the process of rubber products, it is mainly used to put rubber on fabrics, to rubberize fabrics, or to make rubber sheet.

Features:

1. This machine is made of two or more rolls, arranged in a certain form. Under a certain temperature, it can calender rubber or plastic products into sheets with a certain thickness and shape, and it also can rubberize the fiber curtain canvas or steel cord.

2. According to the number of the rolls, it can be divided into 2-roll, 3-roll, 4-roll, 5-roll calendar, etc.

3. according to the arrangement of the rolls, it can be divided into "L" type, "T" type, "F" type, "Z "type and" S "type, etc.

Model XY-230X630 XY-360X1120 XY-400X1400 XY-450X1500 XY-610X1730 XY-710X2130 XY-810X2430
Roller Diameter 230mm 360mm 400mm 450mm 610mm 710mm 810mm
Roller Working Length 630mm 1120mm 1400mm 1500mm 1730mm 2130mm 2430mm
Middle Roller Linear Speed (m/min) 0.8~8 3~21.06 3~26.39 2.62~26.2 5.4~54 8~50 3~30
Nip Adjust Scope (mm) 0.1~7 0.1~10 0.1~10 0.1~10 0.1~15 0.1~15 0.1~15
Max Calendering Product Width 500mm 920mm 1200mm 1300mm 1500mm 1900mm 2150mm
Power 7.5kw 45kw 55kw 75kw 132kw 185kw 220kw
Weight (kgs) 2600 11000 22000 26000 52000 67000 94000

Our main products includes:

★ Mixing Equipment: Rubber Kneader, Two Roll Mill, Rubber Sheeting Mill, Rubber Refining Mill, Rubber Crusher.

★ Curing Equipment: Pillar / Frame Type Plate Vulcanizing Press, Duplex Curing Press, Rubber Tiles Vulcanizing Press, Jaw Vulcanizing Press Machine, Large Plate Vulcanizing Machine, Automatic Plate Vulcanizing Molding Machine, etc.

★ Extruding Equipment: Hot Feed Extruder, Rubber Strainer, EPDM Rubber Extrusion& Vulcanizing Line.

★ Calender Equipment: Two Roll Calender, Three Roll Calender, Four Roll Calender, Inner Liner & Rubber Calender Line.

★ Waste Tires Recycling Equipment: Semi-automatic Waste Tires Recycling Line, Full- automatic Waste Tires Recycling Line, New Type Waste Tires Recycling Line. Fine Rubber Powder Pulverizer.

★ Other Equipment: Reclaimed Rubber Production Line, Batch-Off Cooler, Conveyor Belt Splicing Press, and so on.

Welcome to visit our factory!

Multifunction 7.5KW Three Roll Rubber Calender Machine XY-630Multifunction 7.5KW Three Roll Rubber Calender Machine XY-630

Multifunction 7.5KW Three Roll Rubber Calender Machine XY-630
