Product Name:Belt Tensioner 612700060033 for MAN truck/Ddelong truck / Wechai P13 engine

Product Details:

Tensioning wheel working principle:

The tensioning wheel releases the torque of the pre-tightened plane vortex spring or cylinder torsional spring in the process of working to achieve the purpose of automatically tensioning the accessory belt.

Specification for installation of automatic tensioning wheel:

1, scope,

This specification is applicable to the operation of the automatic tensioning wheel Assembly during installation.

2. Installation steps of abnormal tensioning wheel:

(1)Install and fix the tensioning wheel with M10 countersunk bolt;

(2)The recommended tightening torque of the bolt is :(50±5)N m;

(3) Use a spanner to pull the tensioning wheel arm to the maximum corner;

(4) in a reasonable order will be around the belt pulley, and maintain the correct position;

(5)Slowly loosen the tensioning wheel arm and make it tighten the belt.Pull out the spanner;

The diagram below:

3. Installation steps of the same direction tensioning wheel:

(1) Install and fix the tensioning wheel with M10 flange face bolts;

The tightening torque of the bolt is recommended to be 50±5N m;

(3) Use the square hole spanner to pull the tensioning wheel arm to the maximum corner;

(4) in a reasonable order will be around the belt pulley, and maintain the correct position;

(5)Slowly loosen the tensioning wheel arm and make it tighten the belt.Pull out the spanner. OK.

The diagram below:

4,Points to note during installation of tensioning wheel:

(1) The belt wedge must be in the corresponding slot of the belt pulley;

(2) Check whether the positioning block of the tensioning wheel arm is close to the free position after tensioning the belt. If it is at a small Angle close to the free position, please replace the belt.

(3)When the tensioning wheel is disassembled, follow the steps.

Note: for products with bolts, first pull out the pins in the correct direction during installation.

Service Process:

• First of all, we have service team for communication. Customer service consultants or customer service personnel interact with customers to process complaints, process orders, and provide information about the organization's products and services.
• Secondly, our customer service consultants will follow up the production for our customers. We provide pictures and videos for customers to make sure everything follow the plan directly. After the production is over, the service staff will examine the product and contact the customer as soon as possible.
• Finally, customer service consultants will contact customer for feedback on our products and services after half a year
•

Production Advantage:

---We have passed the IATF16949:2016 quality management certification and have qualified environmental inspection procedures and equipment;.

---We have the Advanced production equipment and process to provide you with high quality and low price products and services；

FAQ:

1, When can I get the price?

We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please tell us by E-mail,so that we will regard your inquiry as the first priority.

2, How can I get a sample to check your quality?

After price confirmation, you can require for samples to check our quality.

3,Can you do the design for us?

Yes. We have a professional team with rich experience in packaging box design and manufacturing. We can manufacture the products as per your requirements.

4,How long can I expect to get the sample?

It will be ready for delivery in 7-10 days. The samples will be sent to you via express and arrive in 3-5 days.

5,What about the lead time for mass production?

Usually 30-45 days after you confirm the PP sample and we received your deposit.
