Custom Cogged V Belt / Adjustable Fan Belt Non - Slipping Feature
Custom Cogged V Belt / Adjustable Fan Belt Non - Slipping Feature
Custom Cogged V Belt / Adjustable Fan Belt Non - Slipping Feature
Custom Cogged V Belt / Adjustable Fan Belt Non - Slipping Feature
Custom Cogged V Belt / Adjustable Fan Belt Non - Slipping Feature
Custom Cogged V Belt / Adjustable Fan Belt Non - Slipping Feature
Specifications
Brand Name :
AiGuoZhe
Model Number :
22x11130le(1050li)(C)
Certification :
IATF 16949: 2016
Place of Origin :
China
MOQ :
50pcs
Price :
US Dollars $0.5-10.43 pcs
Payment Terms :
T/T
Supply Ability :
20000 pcs/ day
Delivery Time :
10-30 days
Packaging Details :
Box+ Carton Box; 40-100pcs/ Outer Carton
Type :
Cog belt； Tooth Belt; V-Belt
Material :
NB ,CR, Rubber
Length :
Inner length 1050mm, Outer length 1130mm; Customized
Guarantee :
At least 50,000 KM
Advantage :
Oil, Heat, Wear Resistance , Resist to compress, acid and alkali
Used :
Machinery, Ships, Trucks, Buses, Cars, Engines, Tractors
Description

Product Name:

AV22*1130le(1050li)Automotive V-Belt；Fan Belt；22*1050liToothed Belt.

Materials: CR/EPDM

Product Details:

(1) Material: CR /NB

(2) We can guarantee this quality can be used at least 50000 Kilometers.

(3) Easy to install.

(4) The length can be customized according to your samples.

(5) It can be customized your own brand and LOGO and the mould is free.

1. Appearance Quality Requirements:

A. Uniform warp and weft density of canvas fabric, without defects affecting quality such as incomplete and distortion.

B, top glue, slow glue, bottom glue uniform composition, appearance without pores, layered impurities and other defects; Fiber dispersion is good and color is consistent.

C. The trademark is clear and complete.

D, V high performance polyester cord with cut edge uniform twist; V-band adult untwisted bend band.

2.Tensile Strength Performance

Utomobile V belt GB12732-2008 National Standard Requirements

Model AV10 AV13 AV15 AV17 AV22
Tensile strength /N ≥ 2260 3140 3700 4420 7060
Reference force elongation /% ≤ 4 4 4 6 6
Reference force /N 790 1480 1800 2360 3930

Ours V with Tensile Strength Performance

Model AV10 AV13 AV15 AV17 AV22
Tensile strength /N ≥ 3200 4500 5300 6400 9000
Reference force elongation /% ≤ 2.4 2.4 2.4 2.4 2.4
Reference force /N 790 1480 1800 2360 3930

3.Size:

V Belt Top Width:

Item AV10 AV13 AV15 AV17 AV22
Top Width 10 12.5 14.5 16.2 21


Change in Center Distanc

Nominal length Le (effective length) mm
Change of center distance, not more than (top width ≤25)
GB13552-2008 Ours
≤1000 ≤1.2 ≤0．2
1001～2000 ≤1.6 ≤0．3
2001～5000 ≤2.0 ≤0．4

Custom Cogged V Belt / Adjustable Fan Belt Non - Slipping Feature

Custom Cogged V Belt / Adjustable Fan Belt Non - Slipping Feature

Custom Cogged V Belt / Adjustable Fan Belt Non - Slipping Feature

FAQ:

1. Production :

We can produce by the size and pics.

If you want the customized products, send the samples to us.

2. Delivery:

The price is FOB price and it would by ship.

3. Samples:

We can provide samples but the delivery fee is paid by the customer.
