Horizontal Cylindrical Pressure Steam Sterilizer 150L 200L 280L 400L 500L
Horizontal Cylindrical Pressure Steam Sterilizer 150L 200L 280L 400L 500L
Horizontal Cylindrical Pressure Steam Sterilizer 150L 200L 280L 400L 500L
Horizontal Cylindrical Pressure Steam Sterilizer 150L 200L 280L 400L 500L
Horizontal Cylindrical Pressure Steam Sterilizer 150L 200L 280L 400L 500L
Horizontal Cylindrical Pressure Steam Sterilizer 150L 200L 280L 400L 500L
Horizontal Cylindrical Pressure Steam Sterilizer 150L 200L 280L 400L 500L
Horizontal Cylindrical Pressure Steam Sterilizer 150L 200L 280L 400L 500L
Horizontal Cylindrical Pressure Steam Sterilizer 150L 200L 280L 400L 500L
Horizontal Cylindrical Pressure Steam Sterilizer 150L 200L 280L 400L 500L
Horizontal Cylindrical Pressure Steam Sterilizer 150L 200L 280L 400L 500L
Horizontal Cylindrical Pressure Steam Sterilizer 150L 200L 280L 400L 500L
Specifications
Brand Name :
ZL
Model Number :
ZL-6024
Certification :
CE,ISO
Place of Origin :
CHINA
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
40 sets / month
Delivery Time :
4-7 work days
Packaging Details :
150L 200L 280L 400L 500L Horizontal Cylindrical Pressure Steam Sterilizer is packaged within wooden case.
Product name :
150L 200L 280L 400L 500L Horizontal Cylindrical Pressure Steam Sterilizer
Working pressure :
0.22 MPa
Working temperature :
134℃
Heating equilibrium :
≤± 2℃
Power/Voltage :
18KW/380V 50Hz
Gross Weight/Net weight :
580/470 KG
Adjustment of Temperature :
105℃ - 134℃
Time of Sterilization :
0-60 min
Time of Drying :
0-60 min
Heat Average :
≤±1℃
Description

150L 200L 280L 400L 500L Horizontal Cylindrical Pressure Steam Sterilizer

Machine Summary:

High Pressure Heat Steam Aging Test Chamber is a new type of electromechanical integration equipment. The mechanical body is a pressure vessel, it is strictly designed and manufactured according to GB150-1998. All the points which directly contact with sterilized item, are made by high quality stainless steel. Safe

and pollution-free, short sterilizing time, easy operation, powerful function and reliable.

Application:

High Pressure Heat Steam Aging Test Chamber is suitable for hospital supply room, operating room,

pharmaceutical factory and scientific research department, etc.

Characteristics:

1. The sterilization process is automatically controlled, without supervision and easy to apply.

2. With drying function to achieve the drying effect of sterilized articles.

3. With over-temperature and over-pressure automatic protection device.

4. Safety interlock device: when the door is not closed tightly good and steam cannot enter the inner main body and alarm, and when the pressure inside the sterilization room is greater than 0.027MPa, the door is interlocked and cannot open the door.

5. Overpressure Protection: The safety valve will automatically release pressure when the pressure exceeds the working pressure.

6. Low water level protection device: The water cannot be started until the high water level is reached, and it is protected by automatic power failure when the low water level is short of water.

7. Over-current protection: when the current is overloaded, the power circuit breaker will automatically cut off the power.

8. Sterilization chamber is made of high quality stainless steel.

Technical Data:

Technical Data ZL6024-150 ZL6024-200 ZL6024-280 ZL6024-400 ZL6024-500

Sterilizing Chamber

Volume

150L

φ440×1000mm

200L

φ515×1000mm

280L

φ600×1000mm

400L

Φ700×1100mm

500L

Φ700×1300mm
Working Pressure 0.22MPa
Working Temperature 134℃

Adjustment

of Temperature

 105℃ - 134℃

Time

of Sterilization

 0-60 min
Time of Drying 0-60 min
Heat Average ≤±1℃
Power 9KW/380V 50Hz 9KW/380V 50Hz 12KW/380V 50Hz 18KW/380V 50Hz 18KW/380V 50Hz
Dimension

1400×600

×1300

1400×670

×1650

1400×770

×1780

1430×880

×1830

 1800×900×1820
Transport Dimension

1550×750

×1850

1560×820

×1850

1680×920

×2100

1800×1050

×2100

 1850×1050×2100
G.W/N.W 320/240 KG 350/260 KG 465/365 KG 530/520 KG 580/470 KG

Horizontal Cylindrical Pressure Steam Sterilizer 150L 200L 280L 400L 500L

Horizontal Cylindrical Pressure Steam Sterilizer 150L 200L 280L 400L 500L
