Specifications
Brand Name :
ZL
Model Number :
ZL-3059
Certification :
CE,ISO
Place of Origin :
CHINA
MOQ :
1 SET
Price :
Negotiable
Payment Terms :
Negotiable
Supply Ability :
60 sets / month
Delivery Time :
4-7 work days
Packaging Details :
Vertical Injection Molding Machine For Small And Medium - Sized Embedded Parts is packaged within wooden case.
Product name :
Vertical Injection Molding Machine For Small And Medium - Sized Embedded Parts
Product use :
AC/DC plug injection molding, other plastic injection molding
Screw diameter :
25mm
Screw speed :
0-200 rpm
Injection amount :
45g
Motor power :
3 kw
Mold opening stroke :
160mm
Key words :
Injection Molding Machine
Description

Vertical Injection Molding Machine For Small And Medium-sized Embedded Parts

Product advantages

1. Vertical clamping, vertical injection, small footprint, smart and precise, suitable for injection molding of small and medium-sized embedded parts, high injection pressure, fast rate of fire, and best choice for thin parts.

2, Direct pressure mode-locking, uniform stress distribution, low-pressure protection, smooth and excellent flow.

3, According to the characteristics of embedded parts and capacity needs, with a skateboard type or turntable type, to achieve the minimum input maximum output.

4, Expandable programming, with automatic embedded, take out equipment connection, fully automatic operation

5. In-line reciprocating screw injection mode device, which uses a hydraulic motor to spirally feed to improve the mixing of materials.

6, 3 section temperature control device, injection speed, back pressure without segment adjustment, suitable for the molding of various precision engineering plastics.

7. The lower mold is fixed, the upper mold is lowered and the mold is closed, and there is a good positioning for the embedded items, and there is a finished product ejection device.

Related Machine:

1.Banbury Mixer 2.Vulcanizing Press Machine

3.Rubber Mixing Mill 4.Three-Roll Grinding Mill

5.Twin-Screw Extruder 6.Moving Die Rheometer

Catalog about Rubber Products:

rubber machine.pdf

Technical parameters:

Product use AC/DC plug injection molding, other plastic injection molding
Screw diameter 25mm
Screw speed 0-200 rpm
Injection amount 45g
Injection pressure 1098Mpa
Theoretical injection capacity 49 cubic centimeters
Motor power 3 kw
Clamping force 15 kN
Mold opening stroke 160mm
Weight 600kg
Dimensions 1400*800*2100 mm

Vertical Injection Molding Machine For Small And Medium - Sized Embedded Parts
