LED Display Dust Laser Particle Counter With Semiconductor Laser Sensor
LED Display Dust Laser Particle Counter With Semiconductor Laser Sensor
LED Display Dust Laser Particle Counter With Semiconductor Laser Sensor
LED Display Dust Laser Particle Counter With Semiconductor Laser Sensor
Specifications
Brand Name :
Zhongli
Model Number :
ZL-6029B
Certification :
ISO,CE
Place of Origin :
Guangdong,China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
100 sets per month
Delivery Time :
5~7 days after the order confirmed
Packaging Details :
Packaged in wooden case （fumigation free）
Sampling flow: :
2.83L/min
Testing range: :
100 degree~1000000 degree
The dust content of testing air range: :
≤10 0000 particles/2.83L
Sampling period: :
1~10 (min)
Grain size channel: :
0.3 , 0.5, 1.0, 3.0, 5.0, 10μm
Clean-down capacity: :
≤10 (min)
Working environment:temperature10~35℃ relative temperature: :
20~75%RH
The max.consumption: :
20W
Sampling times per point: :
2~9 times setting
Sampling number: :
2~7 points setting
Description

LED Display Laser Dust Particle Counter

Summary:
The dust counter is our newly develop portable laser dust particles counter which apply semiconductor laser sensor, can be connected to PC data collection system to remote control, so that can directly observe the testing situation, and the testing data can be analysis, processed and saved as Excel document. The technical index can meet the verification regulation JJG547-88 issued by DGS. The counter apply American micro-computercontrolling and dealing technology, semi-conductor technology and imported air pump, with the character of multi-function, high precision measure, high speed, portable and easy to operate. The counter one time sampling can test the number of dust particles on different kinds of grain sizes. The counter has been wildly used in cleaning room for electronic manufacturing enterprises, filter for on-site test and leak detection, production and scientific researching departments, such as testing biosafety, HVAC system, computer room, beverage packing environment, medicine, medical instrument production environment, hospital cleaning room, spray environment, micro-electronics, biochemicals, food safety, fine chemical engineering,precision machinery, etc. It is the first choice for HVAC,pharmaceutical enterprise and supervisory department.

Main technical parameters and functions:

Product Name LED Display Laser Dust Particle Counter
Light source Laser light source
Sampling capacity 2.83L/min(0.1cfm/min)
Testing range 100 degree~1000000 degree
The dust content of testing air range ≤10 0000 particles/2.83L
Grain size channel 0.3 0.5 1.0 3.0 5.0 10.0(μm)six grade

Display or print the the number of

particles

 1 m3 from the particle in 2.83L/min
Sampling period 1~10 (min)
Clean-down capacity ≤10 (min)
Calibration

Our company already pass the national metrology

building standard assessment
Working environment temperature10~35℃ relative temperature:20~75%RH
The max.consumption 20W

The measuring temperature,humidity

range and precision(options)

(1)Temperature 0~50℃±1℃

(2)Humidity 0~100%RH±5%
Sampling number 2~7 points setting
Sampling times per point 2~9 times setting
UCL statement meet standard FS-209E,China GMP
Working time 8h
Power supply AC220V±10% 50±2Hz
Weight 3.5kg
Dimension 220*280*135mm

The dust content of six grain size can be tested at the same time,

digital display or customize size display

Notes: Built-in printer, automatically judge the cleaning degree, power sampling

head, sampling frame(options: temperature and humidity head)

FAQ

Statement of Warranty

ZhongLi Warrants all the products manufactured by Zhongli to free from defects in material and workmanship under normal use of a period of 12 months or 36months after the date of the original purchase price if repair or replacement is not possible of practical, Zhongli warranty covers ONLY the product itself.

ZhongLi will assume no liability for labor costs, installation costs, or other losses. Your warranty rights will be honored only when the product has been installed and used properly as deemed by ZhongLi , ZhongLi will not repair products damaged by improper use or faulty installation.

In Case of breakage:

All order shipments leave our factory complete and in working order, customer must report and damage within 7days of receipt of order by sending digital photographs(.JPG) of damaged items. Customer must retain damaged merchandise, package and shipping containers until claim had been settled. Damage in transit is the sole responsibility of the carrier, and any claim beyond this 7days period will not be deemed valid by ZhongLi .

Return policy:

ZhongLi will accept returns for a refund within 30days of the shipment of your order. Please note exceptions bellow:

Returns must be first acknowledged by ZhongLi PRIOR to return, Please contact the related salesman in charge . All packages sent to ZhongLi MUST have the initial sales invoice number issued and printed clearly on the outsite of package, A lack thereof will result in the item being immediately restocked and no credit or refund will be issued. All returns must be made in their original packaging with sufficient packing material. Modified or installed items will not be accepted for return.

Thanks for your support to Zhongli !
