Features
1. After oxidation treatment,all aluminum parts are processed by CNC machine and work piece error is 0.1mm.
2. Water level indicator is equipped.
3. Multifunctional socket is equipped which makes water pump and fan installation easy.
4. Stainless steel hexagon screw is applied which is difficult to get rusty.
5. Bearing cover is made by PEEK steel which has friction resistance and heat resistance features. Spring is made by stainless steel which can protect it from rusty and keep good resilience.
6. Big smoke outlet and double fan design is good for discharge smoke and large area engraving.
7. Multifunction display screen is easy for operation and friendly human - machine interface.
8. Embedded HTK linear guide rail makes the machines life time can be 10 years.
9. Double coupling design makes engraving operation more stable.
10.Gallery has 2000 pieces of documents, laser anti-counterfeit fingerprints and thousands of fronts.

Specification:
1.Laser power:40W
2.Voltage:110/220V,50/60Hz
3.Laser power supply:MYJG-40 40W CO2 power supply
4.Engraving mainboard:LaserDRW and CoreLDRAW,etc.
5.Weight:35Kg
6.Machine size:850x500x250mm
7.Max engraving area:330x210mm
8.Max stamp area:195x75mm
9.Place item area:425x210m
10.Engraving accuracy: 0.8x0.8mm,data,English character
11.Eletric l power consumption:210W

Application materials
Apply on jade,MDF,metal,paper,leather,plastic,rubber,crystal and other non metal material.
Payment method: T/T, payment will be transferred to our company bank account.
Delivery time: If purchase is less than 6 sets standard type machine, delivery time is 20-21 working days. If purchase is more than 6 sets or machine is customized, generally the delivery time is 21-30 working days. Foam and wooden box for package.The whole machine warranty is 2 years. While accessories warranty depends on its own warranty. During warranty of machine, if it has problem, spare parts will be shipped to client freely by DHL in 2-3 days. In this way, distributor or machine user can resolve the trouble timely. If machine is out of warranty, we only charge spare parts cost and shipping cost.Our company will offer technical support to machine installation, wiring connection,adjustment or operations from 8:30AM to 5:30PM of china local time each day.
