Vandal proof industial keyboard integrate touchpad pointing device USB or PS/2 interface
Vandal proof industial keyboard integrate touchpad pointing device USB or PS/2 interface
Vandal proof industial keyboard integrate touchpad pointing device USB or PS/2 interface
Vandal proof industial keyboard integrate touchpad pointing device USB or PS/2 interface
Vandal proof industial keyboard integrate touchpad pointing device USB or PS/2 interface
Vandal proof industial keyboard integrate touchpad pointing device USB or PS/2 interface
Vandal proof industial keyboard integrate touchpad pointing device USB or PS/2 interface
Vandal proof industial keyboard integrate touchpad pointing device USB or PS/2 interface
Specifications
Brand Name :
IKB-MKB
Model Number :
K-TEK-A83TP-V02
Certification :
CE, FCC, ROHS, IP65, IP68, ISO 9001-2015
Place of Origin :
Shenzhen, China
MOQ :
1pc
Payment Terms :
Full payment in advance, Western Union, T/T, Paypal
Supply Ability :
3000psc/month
Delivery Time :
ASAP Within 2 weeks upon payment confirmed
Packaging Details :
Each keyboard to one box, several boxes to one carton.
Material :
304 stainless steel
Colour :
Brushed stainless steel or Black
Application :
Kiosk, medical, railway, navy
Dimension :
83.0mm x 86.0mm (front panel)
Interface :
USB or PS/2 interface
Mounting :
Rear Panel mounting
Key Travel :
2 mm long stroke
Description

Vandal proof industial stainless steel touchpad pointing device

Key Features:

1. Designed to operate in harsh environments, making it ideal for application in public place and other harsh environment

2.Stainless steel housing protects the electronics module included

3. CE, FCC, RoHS, IP65, ESD

4.Rear panel mounting.

5. IP65 Sealed and Ruggedized Touchpad mouse with scroll function optional

6.High quality touchpad for fast and accurate cursor position

7. Vandal proof metal stainless steel touchpad with 2 key buttons

8.USB or PS/2 interface optional

Application:

A: INDUSTRIAL: Industrial automation, Banks/Kiosks, pharmaceutical, oil and gas, food and beverage, clean or dirty manufacturing environments, warehouses.


B: MEDICAL: lab, hospital, clinic, dental, such as carts, diagnostic equipments, operation rooms, dialysis centers etc.

C: MATERIAL HANDLING: mobile keyboard, data entry, assembly line etc.


D: MILITARY: Army, Navy, Air force, Marine and Boating etc.

Specifications:

ITEM

SPECIFICATION

Mechanical

Key

2 keys, quality brushed stainless steel

Key top style

Protuberant Rectangular Keys,

Front Plate

Quality brushed stainless steel

Key Travel

2.0mm

Touchpad thickness

1.3 mm PCB thickness inclusive of mylar layer

Key switch lifespan

more than 10 Mio actuations

Touchpad lifespan

10 Mio times

Back Metal Cover

Rear side integrated electronics protected by a metal cover

Actuation Force

1.0N to 3.0N

Mounting Rack

Aluminum alloy

Dimension

Touchpad: 65.0mm x 49.0mm; Front Mounting

Panel: 83.0mm x 110.0mm (front panel),

Rear Mounting Panel: 107.0mm x 134.0mm

Interface

PS2, USB are available, Y type cable with ports of PS2 and USB

Electrical

Power supply

5V DC+ 10%, keyboard interface

Protection level

IP65 (front panel), NEMA3

EMC Standard

EN55022(B)

Power consuming

≤1.00W(dynamic)

≤0.2W(static)

Contact Material

Gold/Carbon

Environmental

Operating temperature

-20ºC~+ 60º C

Storage temperature

- 30ºC~+ 70ºC

Operating RH

30～90%

Atmospheric pressure

60～106Kpa.

Reliable

Certificates

RoHS compliant, CE and FCC certified,IP65,ESD

MTBF

>50000h

MTTR

< 30min

OS

OS is under All windows, Linux, Unix, Mac OS9 / OSX

Packing Details

Each unit to a suitable brown box, suitable brown boxes to a standard export carton.

Application:

Vandal proof industial keyboard integrate touchpad pointing device USB or PS/2 interface

Vandal proof industial keyboard integrate touchpad pointing device USB or PS/2 interface

Vandal proof industial keyboard integrate touchpad pointing device USB or PS/2 interface
