IP65 Waterproof USB Interface Silicone Industrial Keyboard With Touchpad
IP65 Waterproof USB Interface Silicone Industrial Keyboard With Touchpad
IP65 Waterproof USB Interface Silicone Industrial Keyboard With Touchpad
IP65 Waterproof USB Interface Silicone Industrial Keyboard With Touchpad
IP65 Waterproof USB Interface Silicone Industrial Keyboard With Touchpad
IP65 Waterproof USB Interface Silicone Industrial Keyboard With Touchpad
IP65 Waterproof USB Interface Silicone Industrial Keyboard With Touchpad
IP65 Waterproof USB Interface Silicone Industrial Keyboard With Touchpad
Specifications
Brand Name :
IKB-MKB
Model Number :
K-TEK-M276TP-FN-OBL-ML-OEM
Certification :
CE, FCC, ROHS, IP65, IP68, ISO 9001-2015
Place of Origin :
Shenzhen, China
MOQ :
1pc
Payment Terms :
Full payment in advance, Western Union, T/T, Paypal
Supply Ability :
3000psc/month
Delivery Time :
ASAP Within 2 weeks upon payment confirmed
Packaging Details :
Each keyboard to one box, several boxes to one carton.
Interface :
USB or PS/2 available
color :
black
mounting solution :
desk top
key travel :
1.5mm
material :
rubber
backlight :
Red
Keys :
89 keys
Description

IP65 Waterproof USB Interface Silicone Industrial Keyboard With Touchpad

Special Features:

1. Keyboard provides full-size versatility in a rugged, compact design, rugged construction for reliable functionality.
2. Special durable-coating for excellent mechanical and chemical resistance.

3. The keyboard lacks the crevices found between the keys of a regular keyboard, which is protected against dust, dirt, grease and corrosive liquids to NEMA 4X, which means it can withstand directed hose water, disinfectants, environmental contaminants and heavy industrial use.

4. keyboard with NVIS-compliant red adjustable backlighting, while NVIS backlighting makes this keyboard ideal for aviation or vehicle applications where night vision goggles are necessary.
5. 89 keys IP65 dynamic sealed and ruggedized desktop industrial silicone rubber Hygienic keyboard with full keyboard functionalities with sealed and ruggedized tough touchpad

6. Enclosure: industrial silicone and optional stainless steel backplate.

7.Ease of customizing with multiple languages, to accommodate foreign or custom variants.

8. Special durable-coating for excellent mechanical and chemical resistance.

Dimensions: 274.60mm x 146.50mm

MECHANICAL DATA Key: 89 keys
Key top style: Protuberant rectangular keys with tactile feeling.
Touchpad cover: Composite
More than Lifetime 10 million strokes
Mutual Capacitance sensing
X/Y position sensing resolution: 40 counts/mm
X/Y position reporting: Relative
Output (self-detectable depending on cable): PS2 or USB
Tracking speed: Maximum 1,016 m/sec
Power supply voltage: 5 VDC ± 0.25V
Current rating (active mode): 17 mA
Key Size: 12.0mm x 13.0mm for normal keys, 23.4mm x 13.0mm for enter key, 68.0mm x 13.0mm for space bar key.
Cable Length: 2.50m
G.W.: 0.50KGs
ELECTRICAL DATA

Supply Voltage: +5V DC +/-5%
Current Rating: 30mA (non-backlight) , 150mA (with backlight on)
EMC Standard: IEC61000-4-2:2008; IEC61000-4-3:2006+AI:2007+A2:2010; IEC 61000-4-4:2004 EMI: EN55022: 2010
EMS: EN55024: 2010
Lifespan> 3 years
Switch Contact Material: Carbon-on-Gold key switch technology with gold PCB.
Interface: PS2, USB available.
OS: All Windows, Linux, Unix, Mac OSX
ENVIRONMENTAL ADAPTABILITY Operating temperature:-40oC to +80oC
Storage temperature: :-50oC to +90oC
Operating RH: 100%
Atmospheric pressure: 60-106Kpa
Shock: 3x11 ms pulses of 50g on each of 3 axes
Vibration: POWER SPECTRAL DENSITY: 0.04g/Hz, FREQUENCY RANGE: 20Hz - 2kHz, DURATION OF TEST PER AXIS: 3 hours
Flammability
PRINTED CIRCUIT BOARD: 94 VOSILICONE OVERLAY: 94 HBINTERFACE CABLE: 94 V
RELIABILITY RoHS , CE, FCC, ESD
Protection Level: IP65, NEMA 6P
Key Lifespan >10 million actuations
MTBF >50000H
MTTR <30min

Front side:

IP65 Waterproof USB Interface Silicone Industrial Keyboard With Touchpad

Desktop for option:

IP65 Waterproof USB Interface Silicone Industrial Keyboard With Touchpad

Company photo:

IP65 Waterproof USB Interface Silicone Industrial Keyboard With Touchpad
