Waterproof Silicone Industrial Pointing Device Ruggedized In Black
Waterproof Silicone Industrial Pointing Device Ruggedized In Black
Waterproof Silicone Industrial Pointing Device Ruggedized In Black
Waterproof Silicone Industrial Pointing Device Ruggedized In Black
Specifications
Brand Name :
IKB-MKB
Model Number :
K-TEK-M130-25-OTB-KP-OEM
Certification :
CE, FCC, ROHS, IP65, IP68, ISO 9001-2015
Place of Origin :
Shenzhen, China
MOQ :
1pc
Payment Terms :
Full payment in advance, Western Union, T/T, Paypal
Supply Ability :
3000psc/month
Delivery Time :
ASAP Within 2 weeks upon payment confirmed
Packaging Details :
Each keyboard to one box, several boxes to one carton.
Dimension :
130.00mm x 77.51mm (L x W )
Material :
Silicone rubber
GW :
0.5KGS
OEM/ODM :
yes
Interface :
USB or PS/2
Colour :
Black
Mounting :
Rear Panel Mounting
GW. :
0.5 KGS
Description

Waterproof Silicone Industrial Pointing Device Ruggedized In Black

DESCRIPTION: 15 Keys IP65 sealed & Ruggedized Silicone Rubber Industrial Numeric keypad with integrated sealed and ruggedized IP68 dynamic washable 25.0mm optical trackball module with 800 DPI for fast and accurate cursor position, industrial PCB with carbon-on-gold key switch technology with long stroke (1.50mm) with extremely good tactile feeling for fast and accurate data input without any noise, with panel mounting solution. Backlight optional.

MAIN FEATURES:

1. IP65 static mechanical trackball module with military level optional.

2. Ease of customizing with multiple languages, to accommodate foreign or custom variants.

3. Keypad provides is in a rugged, compact design, rugged construction for reliable functionality

4. The trackball pointing device is a completely sealed IP68 dynamic washable 25.0mm optical trackball

5. The keypad lacks the crevices found between the keys of a regular keypad, which is protected against dust, dirt, grease and

6. The trackball is operated using totally sealed switches with left and right click, scroll rolling functions.

7. PS/2, USB connection cables that plug directly into computer like keyboard operations.

MECHANICAL DATA Key: 15 keys
Key top style: Protuberant rectangular keys with tactile feeling.
Switch life: more than 10 million of operations.
Cable Length: 2.50m
G.W.: 0.60KGs
Dimensions: 130.00mm x 77.51mm (L x W )
ELECTRICAL DATA

Supply Voltage: +5V DC +/-5%
Current Rating: 50mA (non-backlight) , 120mA (with backlight on)

Power: 0.25W (non-backlight), 0.60W (with backlight on)
EMC Standard: It is compliance with the council IEC 61000-4-2:2008；IEC 61000-4-3:2006+AI:2007+A2:2010；IEC 61000-4-4:2004

EMI: EN 55022: 2010

EMS: EN 55024:2010
Lifespan> 3 years
Switch Contact Material: Carbon-on-Gold key switch technology with gold PCB.
Interface: PS2, USB available.
OS: all Windows, Linux, Unix, Mac OSX
ENVIRONMENTAL ADAPTABILITY Operating temperature:-20oC to +65oC
Storage temperature: -40oC to +80oC
Humidity: 100%
Atmospheric pressure: 60-106Kpa
RELIABILITY RoHS, CE and FCC, ESD
Protection Level: IP65, NEMA 6P
Key Lifespan >10 million actuations
MTBF >50000H
MTTR <30min

Actual Photos:

Waterproof Silicone Industrial Pointing Device Ruggedized In Black

Waterproof Silicone Industrial Pointing Device Ruggedized In Black


Waterproof Silicone Industrial Pointing Device Ruggedized In Black
