IP65 Stainless Steel Backlit USB Keyboard With Tough Touchpad
IP65 Stainless Steel Backlit USB Keyboard With Tough Touchpad
IP65 Stainless Steel Backlit USB Keyboard With Tough Touchpad
IP65 Stainless Steel Backlit USB Keyboard With Tough Touchpad
IP65 Stainless Steel Backlit USB Keyboard With Tough Touchpad
IP65 Stainless Steel Backlit USB Keyboard With Tough Touchpad
Specifications
Brand Name :
IKB-MKB
Model Number :
K-TEK-A343TP-BL-DWP
Certification :
CE, FCC, ROHS, IP65, IP68, ISO 9001-2015
Place of Origin :
Shenzhen, China
MOQ :
1pc
Price :
to be quoted
Payment Terms :
Full payment in advance, Western Union, T/T, Paypal
Supply Ability :
3000psc/month
Delivery Time :
ASAP Within 2 weeks upon payment confirmed
Packaging Details :
Each keyboard to one box, several boxes to one carton.
material :
Stainless steel
connection :
USB / PS2
application :
Indutrial
Backlight color :
Blue
G.W. :
1.80KGs
Name :
Backlit USB Keyboard
Description

DESCRIPTION: 70 keys compact format IP65 dynamic washable vandal proof stainless steel industrial keyboard with IP65 dynamic sealed & ruggedized tough touchpad with scroll function (optional)for fast and accurate cursor position, industrial PCB with carbon-on-gold key switch technology with long stroke (1.5±0.10mm) with extremely good tactile feeling for fast and accurate data input without any noise. one complete sealing silicone rubber above rear stainless steel plate for easy mounting & sealing tightly with cabinet, rear stainless steel plate with mounting holes for rear panel mounting solution. Stainless steel key caps etched out via special professional way and filled with transparent epoxy for backlight out, with adjustable industrial backlight included.(Blue, Red, White colors etc. optional). Which is good for outdoor application with direct rain and very harsh environments with humidity, much dynamic water, oil, dirt, salt mist etc.

DIMENSIONS: 343.0mm x 105.0mm (Top Panel)

MECHANICAL DATA
Actuator/keys 70 keys (Including 2 mouse buttons)
Key top style Protuberant rectangular keys, laser engraved & etched legends & raised braille on keys are available
Key Size 14.0mm x 14.0mm for normal keys, 14.0mm x 28.0mm for enter key, 14.0mm x 70.0mm for space bar
Front Plate 1.5mm thickness super quality brushed stainless steel
Back Plate 1.5mm thickness super quality brushed stainless steel
Key travel 1.5±0.10mm
Actuation Force 1.5N±0.2N for key 14.0mm x 14.0mm (pressure point ), 2.5N±0.2N for key 14.0mm x 28.0mm (pressure point)
Switch life more than 5 million of operations
Touch pad sealed and ruggedized tough touchpad
Touchpad cover Composite
More than Lifetime 10 million strokes
Mutual capacitance sensing
X/Y axis location detection resolution 40 Counts /mm
X/Y position report relative
Output (self-detectable depending on cable) PS2 or USB
Tracking speed Maximum 1,016 m/sec
Power supply voltage 5VDC ± 0.25V
Current rating (active mode) < 10 mA
G.W. 1.80KGs
ELECTRICAL DATA
Supply Voltage DC +5V±5%
Current Rating 50mA when backlight is off, 300mA with backlight on
EMC Standard EN 55032:2015 EN 55035:2017
Lifespan > 5 years
Switch Contact Material Carbon-on-Gold key switch technology PCB
Interface PS2, USB available
OS All Windows, Linux, Unix, Mac OSX, Vxworks, Android, (U-cos--To be confirmed).
ENVIRONMENTAL ADAPTABILITY
Operating temperature -20℃ to +65℃
Storage temperature -30℃ to +75℃
Operating RH 30-90%
Atmospheric pressure 60-106Kpa
Saline mist 96 hours, IEC 60512-6
Damp heat test at +40℃ 21 days, IEC 60512-6
Dry heat test at +85℃ 10 days, IEC 60512-6
RELIABILITY
RoHS Compliant, CE and FCC, ESD
Protection Level IP65 dynamic (front panel)
Vandal resistant IK08
Key Lifespan >5 million actuations
MTBF >20000H
MTTR <30min
APPLICATIONS Industrial, coal and mine, medical, bank kiosk and self service terminal, public access, explosion-proof automation, oil and gas etc.
