Ruggedied Silicone Rubber Military Level Touchpad With Resistor
Ruggedied Silicone Rubber Military Level Touchpad With Resistor
Ruggedied Silicone Rubber Military Level Touchpad With Resistor
Ruggedied Silicone Rubber Military Level Touchpad With Resistor
Specifications
Brand Name :
IKB-MKB
Model Number :
K-TEK-M90TP-DHP-NV-151B
Certification :
CE, FCC, ROHS, IP65, IP68, ISO 9001-2015
Place of Origin :
Shenzhen, China
MOQ :
1pc
Price :
To be quoted
Payment Terms :
Full payment in advance, Western Union, T/T, Paypal
Supply Ability :
3000psc/month
Delivery Time :
ASAP Within 2 weeks upon payment confirmed
Packaging Details :
Each keyboard to one box, several boxes to one carton.
Colour :
Black
Size :
90.0mm x 90.0mm
Mounting :
Rear Panel Mounting
Interface :
USB
MOQ :
1pcs
MTTR :
< 30min
Actuation Force :
1.2N+/-0.1N
Protection Level :
IP67
Operating temperature :
-40℃ to +60℃
Description

Military level ruggedied silicone rubber touchpad with force sensing resistor

Model NO: K-TEK-M90TP-DHP-NV-151B

DESCRIPTION: IP67 dynamic sealed and ruggedized silicone rubber military touchpad with a Force Sensing Resistor pointing device for fast and accurate cursor position, with military level PCB with carbon-on-gold key switch technology with 1.2mm key stroke for fast and accurate data input , 3 mouse buttons for right & left clicking and scrolling up and down, with mounting holes for rear panel mounting. Military level, designed to meet MIL-STD-416G and MIL-STD-810F with strong anti-interference and low radiation ability

Dimensions: 90.0mm x 90.0mm

APPLICATIONS:
MEDICAL: lab, hospital, clinic, dental, such as carts, diagnostic equipments, operation rooms, dialysis centers etc;
MATERIAL HANDLING: mobile keyboard, data entry, assembly line etc
MILITARY: Army, Navy, Air force
INDUSTRIAL: Industrial automation, pharmaceutical, oil and gas, food and beverage, clean or dirty manufacturing
environments, warehouses
OTHER INDUSTRIES
MAIN FEATURES:
IP67 dynamic Sealed and Ruggedized Touchpad for fast and accurate cursor position
Special dura-coating for excellent mechanical and chemical resistance
With firm tactile key feel, key travel 1.2mm.
Waterproof execution according to IP67 protection from top silicone cover for waterproof/dirtproof/weatherproof and
easy cleaning, with mounting holes on the edge for easy tightly mounting to enclosure or panel.
USB connection cables that plug directly into computer like normal mouse operations.
MIL-STD-416G and MIL-STD-810F standard, with strong anti-interference and low radiation ability, electromagnetic
compatibility and wide temperature.
ITEM SPECIFICATION
MECHANICAL DATA Key 2 keys +1 Hula point button
Key top style Protuberant rectangular keys with tactile feeling
G.W. 0.13KGs
Touchpad cover Composite
Switch life 38.0mm
Key switch lifespan more than 5 million of operations.
X/Y Position Resolution 1000 points/inch(40 points/mm)(graphics tablet mode)
Validated touch width 43.0mm (max)
Validated touch length 59.0mm (max)
Dimension

90.0mm x 90.0mm (Front panel)
Interface USB
Electrical Power supply +5V DC +/-5%
Protection level IP67
EMC Standard EN 55032:2015, EN 55035:2017
Power consuming ≤1.00W(dynamic)
≤0.2W(static)
Environmental Operating temperature -40ºC~+ 60º C
Storage temperature -45ºC~+ 70ºC
Operating RH 30～90%
Atmospheric pressure 60～106Kpa.
Reliable Certificates RoHS compliant, CE and FCC certified
MTBF >20000h
MTTR < 30min
OS All Windows, Linux, Unix, Mac OSX, Vxworks, Android, (U-cos--To be confirmed)
Packing Details Each unit to a suitable brown box, suitable brown boxes to a standard export carton.
1, Meet MIL-STD-461G with EMC (Electro Magnetic Compatibility) etc.:
CE101 25Hz - 10kHz Conducted Emissions, Audio Frequency Currents, Power leads
CE102 10kHz -10MHz Conducted Emissions, Radio Frequency Potentials, Power leads
CS101 25Hz - 150kHz Conducted Susceptibility, Power Leads
CS106 Conducted Susceptibility, Transients, Power Leads
CS112 Electrostatic Discharge Susceptibility
CS114 4kHz -400MHz Conducted Susceptibility, Bulk Cable injection
CS115 Conducted Susceptibility, Bulk Cable injection, Impulse Excitation
CS116 10kHz - 100MHz Conducted Susceptibility, Damped Sinusoidal Transients, Cables and Power Leads
RE101 25Hz -100kHz Radiated Emissions, Magnetic Field
RE102 10kHz - 18GHz Radiated Emissions, Electric Field
RS101 25HZ - 100kHz Radiated Susceptibility, Magnetic Field
RS103 10kHz - 40GHz Radiated Susceptibility, Electric Field
2, MIL-STD-810F (wide temperature, shock, vibration, humidity).
ENVIRONMENTAL ADAPTABILITY:
Operating temperature:-40℃ to +60℃
Storage temperature: :-45℃ to +70℃
Operating RH: 100%
Humidity: 93±3%
Atmospheric pressure: 60-106KpaRELIABILITY
RoHS , CE, FCC
Protection Level: IP67
Key Lifespan >5 million actuations
MTBF >20000H
MTTR <30min

Product Image:

Ruggedied Silicone Rubber Military Level Touchpad With Resistor
Ruggedied Silicone Rubber Military Level Touchpad With Resistor
