Silicone Waterproof Touchpad Keyboard 89 Keys IP67 Dynamic Sealed
Silicone Waterproof Touchpad Keyboard 89 Keys IP67 Dynamic Sealed
Silicone Waterproof Touchpad Keyboard 89 Keys IP67 Dynamic Sealed
Silicone Waterproof Touchpad Keyboard 89 Keys IP67 Dynamic Sealed
Silicone Waterproof Touchpad Keyboard 89 Keys IP67 Dynamic Sealed
Silicone Waterproof Touchpad Keyboard 89 Keys IP67 Dynamic Sealed
Specifications
Brand Name :
IKB-MKB
Model Number :
K-TEK-M276TP-FN-BL-ML-OEM
Certification :
CE, FCC, ROHS, IP65, IP68, ISO 9001-2015
Place of Origin :
Shenzhen, China
MOQ :
1pc
Price :
To be quoted
Payment Terms :
Full payment in advance, Western Union, T/T, Paypal
Supply Ability :
3000psc/month
Delivery Time :
ASAP Within 2 weeks upon payment confirmed
Packaging Details :
Each keyboard to one box, several boxes to one carton.
Interface :
USB or PS/2 available
color :
black
mounting solution :
top panel mount
key travel :
1.5mm
material :
silicone rubber
backlight :
optional
Description

Silicone Waterproof Touchpad Keyboard Military Level With Adjustable Backlight

Special Features:

1: 89 keys IP67 dynamic sealed and ruggedized industrial silicone rubber Hygienic keyboard with full keyboard functionalities with sealed and ruggedized tough touchpad for fast and accurate cursor position
2: Special industrial PCB with carbon-on-gold key switch technology with long stroke (1.50mm) with extremely good tactile feeling for fast and accurate data input without any noise
3: FN + Clean key to lock/disable the keyboard for easy cleaning without taking the keyboard from PC
4: Top panel mounted. Adjustable industrial backlight included, military level
5: Durable coating & antimicrobial keyboard surface withstand to most chemicals and liquids under harsh environment
MECHANICAL DATA
Key: 89 keys
Key top style: Protuberant rectangular keys with tactile feeling.
Touchpad cover: Composite
More than Lifetime 10 million strokes
Mutual Capacitance sensing
X/Y position sensing resolution: 40 counts/mm
X/Y position reporting: Relative
Output (self-detectable depending on cable): PS2 or USB
Tracking speed: Maximum 1,016 m/sec
Power supply voltage: 5 VDC ± 0.25V
Current rating (active mode): 17 mA
Key Size: 12.0mm x 13.0mm for normal keys, 23.4mm x 13.0mm for enter key, 68.0mm x 13.0mm for space bar key
G.W.: 0.80KGs
ELECTRICAL DATA
Supply Voltage: +5V DC +/-5%
Current Rating: 50mA (non-backlight) , 300mA (with backlight on)
EMC Standard: EN 55032:2015
EN 55035:2017
MIL-STD-810F (wide temperature, shock, vibration, humidity)
Lifespan> 5 years
Switch Contact Material: Carbon-on-Gold key switch technology with gold PCB.
Interface: PS2, USB available.
Cable length: Standard 2.0m, customized length available.
OS: All Windows, Linux, Unix, Mac OSX, Vxworks, Android, (U-cos--To be confirmed).
ENVIRONMENTAL ADAPTABILITY
Operating temperature:-40℃ to +85℃
Storage temperature: :-45℃ to +90℃
Saline mist:96h, IEC60512-6
Damp heat test at +40℃: 21 days, IEC 60512-6
Dry heat test at +85℃: 10 days, IEC 60512-6
Operating RH: 100%
Atmospheric pressure: 60-106Kpa
Shock: 3x11 ms pulses of 50g on each of 3 axes
Vibration: POWER SPECTRAL DENSITY: 0.04g/Hz, FREQUENCY RANGE: 20Hz - 2kHz, DURATION OF TEST PER AXIS: 3 hours
Flammability
PRINTED CIRCUIT BOARD: 94 V-0 SILICONE OVERLAY: 94 HB INTERFACE CABLE: 94 HB
RELIABILITY
RoHS , CE, FCC
Protection Level: IP67
Key Lifespan >5 million actuations
MTBF >20000H
MTTR <30min

More Photo:

Silicone Waterproof Touchpad Keyboard 89 Keys IP67 Dynamic Sealed

Silicone Waterproof Touchpad Keyboard 89 Keys IP67 Dynamic Sealed

Silicone Waterproof Touchpad Keyboard 89 Keys IP67 Dynamic Sealed

Our Factory:

Silicone Waterproof Touchpad Keyboard 89 Keys IP67 Dynamic Sealed

Silicone Waterproof Touchpad Keyboard 89 Keys IP67 Dynamic Sealed

Silicone Waterproof Touchpad Keyboard 89 Keys IP67 Dynamic Sealed
