High Durability Rugged Android Tablet With Multipoints Capacitive Touch Panel
High Durability Rugged Android Tablet With Multipoints Capacitive Touch Panel
High Durability Rugged Android Tablet With Multipoints Capacitive Touch Panel
High Durability Rugged Android Tablet With Multipoints Capacitive Touch Panel
Specifications
Brand Name :
BATL
Model Number :
BT81
Certification :
CE/ROHS/IP67
Place of Origin :
SHENZHEN,CHINA
MOQ :
1
Price :
negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
2000 pieces/month
Delivery Time :
5-25 working days
Packaging Details :
Gift box 357*186*60mm,1.4kg/piece, cartoon box 10 pieces/cartoon,635*375*220mm
Type :
rugged tablet pc
display size :
8.0 inch Android 8.1
memory :
2GB RAM+32GB ROM
camera :
front 2.0M+rear 5.0M
battery :
6000 mAh
Navigation :
GPS+GLONASS
data transfer :
3G/LTE
Dimension :
225*143*19mm
Optional :
NFC reader,barcode scanner
optional accessories :
vehicle mount,docking station,stylus
Description

Rugged Tablet Pc Rugged Android Tablet 8 Inch Rugged Tablet BT81

IP67 8.0 inch Rugged tablet with option modules 1D/2D barcode scanner and NFC reader,entry level rugged tablet Android 8.1 OS the model with MTK Quad-core CPU,Dual band 2.4/5.8G WIFI,BT 4.0 and 3G/LTE etc wireless data transfer,Corning Gorilla tempered glass touch panel and double injection mould housing to make it MIL-STD-810G standard and shockproof and sealed completely to make it waterproof,and Meanwhile the model with 2.0M front camera and 5.0M rear one,Built in 6000mah big battery to make it continuously working 10-14 hours,Now our customers they mainly use the devices in fleet management and warehouse management and some install their own Application to control special projects

BTW,HDMI,D.C,Micro USB,Type A etc ports,And we also have hand strap to better hold the device,protection slide from hand,Docking station for better charging and vehicle mount fixing tools and charging on the vehicle,

Product Outlook
Type Details Standard Configuration
Product Form Type Rugged Tablet
Dimension 227.5*150*21mm
Weight Device unit: 0.558kg ,Unit with giftbox and standard accessories:1330g,docking:290g
Device Color black( bottom shell in black, front shell in black)
LCD Screen Size 8“ 16:10
Resolution 800*1280 IPS
Brightness 250 nits
TP Touch Panel Multipoints Capacitive,G+G,
Camera Front Front: 2.0MP
Rear Rear: 5.0MP
Speaker Built-in Embedded 8Ω/0.8W waterproof speakerx 1
Mic Built-in Sensitivity:-42db, output resistance2.2kΩ
Battery Type Build in Polymer li-ion battery
Capacity 3.7V/6000mAh
Endurance 10Hrs
System Hardware Configuration
Type Details Description
CPU Type MTK 8735A
Speed 1.45GHZ
GPU Type ARM ® Cortex-A53
RAM DDR3L 2GB
ROM Emmc 32GB
Light sensor Built-in Light sensor
Electronic compass Built-in electronic compass
Gyroscope Built-in gyroscope
G_sensor Built-in Gravity acceleration sensor
Network Connections
Type Details Descriptions
WIFI WIFI module WIFI 802.11(a/b/g/n) frequency 2.4G+5.8G dual band WIFI,
Bluetooth Built-in BT4.0 (BLE) class1.5 transmission distance:10m
2G/3G/4G Built-in GSM/WCDMA Quad band,TD-SCDMA(B34,B39) & TDD(B38,B39,B40,B41)& FDD(B1,B2,B3,B4,B5,B7,B8,B 17,B 20)
NFC option ST 13.56MHz support SO/IEC 14443A/14443B/15693/18092/mifare protocol, Card reading distance: 4cm
GPS Built-in MTK6625 4 in one,GPS+GLONASS
2D Barcode Scanner option Honeywell N3680 Optical Resolution:1280*800；5mil Scan speed:50/s Symbol system:PDF417, MicroPDF417, Data Matrix,
Interface Configuration
Type Details Descriptions
TF slot Extensive External Memory support SDHC/SDXC x1 max: 128G
SIM slot SIM card SIM card x1
USB interface data transmission USB 2.0*1
Earphone Jack Audio Output ∮3.5mm standard earphone jack x1
DC Jack Power DC 5V 3A ∮3.5mm Power connector x1
HDMI interface Video Output HDMI 1.4a Type C x1
Extensive Slot pogo Pin 12pin Pogo Pin x1
Power on press key power key x1
Volume + - press key power key x1,Volume + - x2
Standard Accessories
Type Details Description
OTG cable OTG cable USB OTG to MICRO USB cable length:45mm
USB cable USB cable USB to micro 5P L=1.2M 4core aluminum foil shield cable
Power Adaptor Standard AC100V ~ 240V, 50Hz/60Hz output DC 5V/3A USA Standard CE approval
Optional Accessories
vehicle mount vehicle mount vehicle mount with charging/data transfer or USB transfer into RJ45
docking station docking station docking station for charging and RJ45
stylus stylus stylus
Software Configuration
Type Details Description
Operation System OS version Android 8.1
Reliability
Type Details Descriptions
Product Reliability Drop Height 1.2m composite wood floors, in operation status
Operate Temperature ‘-10 °C to 50 °C (-20 °C to 60 °C optional)
Store Temperature ’-30 °C to 70 °C
Humidity Humidity: 95% Non-Condensing

Why choose us

1. High Quality Products

IP64/IP67/CE/FCC

100% Strictly quality control Before Delivery !

2. Experienced

More than 8 years experience in Hardware rugged tablet and handheld computer

R&D and oversea sales, we know how to communicate with our partners to get what they need

3. Satisfied Service

Before-Sale Service------quick response within ONE working day; experienced sales to know better customers requirements

On-Sale Service---------- delivery on time; quality and quantity assured

After-Sale Service--------One year warranty ; technology support during your project.

Free SDK fro secondary development
