High Sensitivy Rugged Windows Tablet With 8.0 Inch 1280*800 380 Nits Brightness Display
High Sensitivy Rugged Windows Tablet With 8.0 Inch 1280*800 380 Nits Brightness Display
High Sensitivy Rugged Windows Tablet With 8.0 Inch 1280*800 380 Nits Brightness Display
High Sensitivy Rugged Windows Tablet With 8.0 Inch 1280*800 380 Nits Brightness Display
Specifications
Brand Name :
BATL
Model Number :
BT686
Certification :
CE/ROHS/IP67
Place of Origin :
SHENZHEN,CHINA
MOQ :
1
Price :
negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
2000 pieces/month
Delivery Time :
5-25 working days
Packaging Details :
Gift box 357*186*60mm,1.4kg/piece, cartoon box 10 pieces/cartoon,635*375*220mm
Type :
rugged windows 10 tablet
display size :
8.0 inch windows 10
camera :
front 2.0M+rear 5.0M
memory :
4GB RAM+64GB ROM
battery :
8500 mAh
optional accessories :
vehicle mount,docking station,stylus
Navigation :
GPS+GLONASS
data transfer :
3G/LTE
Barcode scanner :
Honeywell N3680
Dimension :
225*143*19mm
Description

Rugged Windows 10 Tablet Rugged Windows Tablet Rugged Windows BT686

Intel Cherry trail Quad core Windows 10 Home or Windows 10 pro

4GB RAM /64GB ROM

◪ Corning Gorrila tempered glass and Double injection mould housing for better protection

◪ 8.0 inch IP67 1280*800 380 nits brightness display

◪ Dual band WIFI,BT 4.0,2G/3G/LTE for data transfer

GPS/GLOANSS navigation

◪ Front 2.0M and rear 5.0M camera

◪ 8500mah big battery for whole day working

◪ Option 1D/2D Barcode scanner for warehouse managment

Micro USB,Type A etc ports

Option vehicle mount for fleet management

Product Outlook
Type Details Standard Configuration
Product Form Type Rugged Tablet
Dimension 225*143*19mm
Weight Device unit: 0.558kg ,Unit with giftbox and standard accessories:1330g,docking:290g
Device Color black( bottom shell in black, front shell in black)
LCD Screen Size 8“ 16:10
Resolution 800*1280 IPS
Brightness 320 Nit
TP Touch Panel Multipoints Capacitive,G+G,Rigidity: above 7H-Anti-scratch,TP thickness:1.1mm,COF,support handwriting
Camera Front Front: 2.0MP with indicator light
Rear Rear: 5.0MP
Speaker Built-in Embedded 8Ω/0.8W waterproof speakerx 1
Mic Built-in Sensitivity:-42db, output resistance2.2kΩ
Battery Type Build in Polymer li-ion battery
Capacity 3.7V/8500mAh
Endurance 8Hrs(default 50% volumn,default200 lumens brightness,play 1080P HD video)
System Hardware Configuration
Type Details Description
CPU Type Intel Cherrytrail Z8350/Z8300 or Baytrail Z3735F
Speed 1.33Ghz-1.92GHz
GPU Type Intel HD Graphic(Gen7)
RAM DDR3L 4GB
ROM Emmc 64GB
Electronic compass Built-in electronic compass
Gyroscope Built-in gyroscope
G_sensor Built-in Gravity acceleration sensor
Network Connections
Type Details Descriptions
WIFI WIFI module WIFI 802.11(a/b/g/n) frequency 2.4G+5.8G dual band WIFI,
Bluetooth Built-in BT4.2 (BLE) class1.5 transmission distance:10m
3G Built-in IC:H350-A30-20 bands: WCDMA(900/2100MHz) GSM(900/1800MHz), HSDPA 7.2Mbps, HSUPA 5.7Mbps, LGA interface
LTE Built-in European version/South American/North American version etc
1D/2D Barcode option 2D QR code Scanner: MOTO SE2707 Hardware decoder,Scan Speed: 50 times/s,Optical resolution: 5mil
Support code system: PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse Maxicode, QR Code, Han Xin Inverse.
NFC option NXP NFC 13.56MHz support SO/IEC 14443A/14443B/15693/18092/mifare protocol, Card reading distance: 4cm
GPS Built-in U-blox NEO-7, support : GLONASS,QZSS,GPS; Capture sensitivity: -160 dBm; Cool Start Time: <30 seconds, Hot start time: <28 seconds, frequency: 0.25 Hz … 10 MHz
Interface Configuration
Type Details Descriptions
TF slot Extensive External Memory support SDHC/SDXC x1 max: 128G
SIM slot SIM card SIM card x1
USB interface data transmission USB 2.0*1 (Host)for windows Android OTG x1
Earphone Jack Audio Output ∮3.5mm standard earphone jack x1
DC Jack Power DC 5V 3A ∮3.5mm Power connector x1
HDMI interface Video Output HDMI 1.4a Type C x1
Extensive Slot pogo Pin 12pin Pogo Pin x1
Power on press key power key x1
Volume + - press key power key x1,Volume + - x2
Standard Accessories
Type Details Description
OTG cable OTG cable USB OTG to MICRO USB cable length:45mm
USB cable USB cable USB to micro 5P L=1.2M 4core aluminum foil shield cable
Power Adaptor Standard AC100V ~ 240V, 50Hz/60Hz output DC 5V/3A USA Standard CE approval
Software Configuration
Type Details Description
Operation System OS version windows 10 HOME Default language: English or Android 5.1
Windows 10 Pro optional
Product Certificate
Type Details Description
Certificate System IP67 IPX7
Method name:short time submerging test
test device and test condition:submerge water box.the size should make the testing sample into submerge box and after then , the distance from sample bottom to water surface at least 1m. and distance from sample top side to water surface at least 0.15m.
Testing time: 30 min
CE YES
810G YES
Battery UN38.3, MSDS, IEC62133
Reliability
Type Details Descriptions
Product Reliability Drop Height 1.2m composite wood floors, in operation status
Operate Temperature ‘-10 °C to 50 °C (-20 °C to 60 °C optional)
Store Temperature ’-30 °C to 70 °C
Humidity Humidity: 95% Non-Condensing

Shipping:
We offer as many shipping options as possible, including DHL, UPS, TNT, FedEx and EMS, Airfreight and by Sea

Import taxes:
When you import products from another country, there is always the possibility of paying import taxes. We can help you reduce and avoid import taxes by declaring prices low, declaring the contents as "electronic accessories" or other items and shipping in simple packaging.

Warranty:
All electronic products (included brand ones) may have problem after used by a period of time. We provide 1 year warranty for all products. Please contact us if you need our detail warranty term.


Our Quality:

Quality is the life of Honesty. We use only the best quality (original) components to ensure the standard of our product range is of the highest caliber.
All products we sold out are strictly selected and tested by our QC department.
