Ruida Laser Controller RDM4024G-PCI Standard Marking Card Laser Marking Controller

Description Of Ruida Controller RDM4024G-PCI

The RDM4024G-PCI marking control card is a sophisticated motion controller tailored by Ruida Technology for laser galvanometer applications. This controller leverages the PCI bus, adhering to standard PCI specification standards, to ensure compatibility and performance.

The hardware foundation of this control card is rooted in an industrial-grade DSP (Digital Signal Processor) combined with an FPGA (Field-Programmable Gate Array) architecture. This combination provides a robust and versatile platform for high-performance computing and real-time control.

Incorporating state-of-the-art galvanometer control algorithms and laser synchronous control algorithms, the RDM4024G-PCI achieves exceptional trajectory control of the galvanometer. This precision is crucial for applications requiring accurate and rapid laser marking.

Efficiency in data communication is further enhanced through the use of bi-directional DMA (Direct Memory Access) operations. DMA allows data to be transferred directly between memory and the controller, bypassing the CPU. This reduces processing overhead and significantly boosts the speed of data transfer, thereby enhancing the overall performance of the system.

In summary, the RDM4024G-PCI marking control card is a high-performance, reliable, and efficient solution for laser galvanometer applications. Its advanced hardware architecture and sophisticated algorithms make it an ideal choice for precise and rapid laser marking tasks.

Product Photo

Application Fields

Equipped with CO2 laser, suitable for marking of wood, leather, plastics and paper. Equipped with fiber laser, suitable for marking of stainless steel, aluminium oxide, copper oxide and other alloy materials, including jewelry, metal, electronic components, battery, charger, switch, etc. Equipped with UV laser, suitable for precision marking in electronic industry, including plastic, PVC,electronic circuit board, cable, chip, LCD screen, glass, food packaging, etc.

Software

LaserMark

Product Certification
