380~420v ZP90KCE-TFD-522 R410a 7.5hp Copeland Scroll Compressor
380~420v ZP90KCE-TFD-522 R410a 7.5hp Copeland Scroll Compressor
380~420v ZP90KCE-TFD-522 R410a 7.5hp Copeland Scroll Compressor
380~420v ZP90KCE-TFD-522 R410a 7.5hp Copeland Scroll Compressor
380~420v ZP90KCE-TFD-522 R410a 7.5hp Copeland Scroll Compressor
380~420v ZP90KCE-TFD-522 R410a 7.5hp Copeland Scroll Compressor
380~420v ZP90KCE-TFD-522 R410a 7.5hp Copeland Scroll Compressor
380~420v ZP90KCE-TFD-522 R410a 7.5hp Copeland Scroll Compressor
Specifications
Brand Name :
copeland
Model Number :
ZP90KCE-TFD-522
Certification :
CE
Place of Origin :
China
MOQ :
1 pieces
Price :
discussed
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1000piece/month
Delivery Time :
3 days
Packaging Details :
wooden box
Brand :
Copeland
color :
Black
Condition :
New
Warranty :
1 YEAR
Refrigerant :
R404
Type :
Refrigeration Compressor
Description
Product Description

1. Copeland compressor have Ultra high energy efficiency.
2. High Heat Pump Capacity Due to Nearly 100% Volumetric Efficiency.
3. Wide Selection Range
50 Hertz 18200 to 68000 BTUH
4590 to 17100 KCALH
5330 to 19900 WATTS .
4. Fewer Moving Parts
5.The motor can effectively protect the motor from the damage of high temperature and high voltage current, low noise low exhaust impulse noise value is lower than piston compressor 5 dB.
6. Rugged Design and Proven Durability.
7. Unloaded Start Feature Requires No Start Capacitors
8. Straight Suction Tube Allows For Low Profile Application
9. Performance Improves as Scroll Sets Wear-In
10. Internal Motor Protection with Start Winding Protection on Single Phase Models

Product Name
Best price 7.5hp 380~420v r410a copeland scroll compressor ZP90KCE-TFD-522
Material
stainless steel
Cooling capacity
74500Btu/hr
Voltage
380/420V ,50Hz, 3phase
Refrigerant
410A
Weight
56.7kg
Dimension
0.025 cbm/pc
Leading time
about 10 days once the order is confirmed

Model: ZP90KCE-TFD

Technical data
Displacement [m³/h]: 14,6
Sound power [dBA]: 72
Sound pressure level [dB]: 61
Net Weight [kg]: 56,7
Gross Weight [kg]: 67
Oil charge [dm³]: 2,5
Maximum high pressure [bar]: 45
Maximum standstill pressure [bar]: 29,5
Minimal lowside temperature [°C]: -35
Maximum lowside temperature [°C]: 50
PED category: 2

Electrical data
Power supply [V/~/Hz]: 380-420V/3/50Hz
Locked rotor current [A]: 95,0
Max. operating current [A]: 16,0
Winding resistance [Ω]: 1,6

Connections
inches
Suction connection with supplied sleeve: 1 1/8"
Discharge connection with supplied sleeve: 7/8"

Standard equipment
  • screwed sight glass
  • Rotalock connections
  • Schraeder connection
  • assembly washer
  • discharge temperature control

Optional equipment
  • external crankcase heater (70W)

Application
  • medium temperatures (from 7 ºC to -30 ºC)
  • refrigerant R410A
