1500W Handheld Laser Welding Machine Laser Metal Soldering Machine 110V/ 220V
1500W Handheld Laser Welding Machine Laser Metal Soldering Machine 110V/ 220V
1500W Handheld Laser Welding Machine Laser Metal Soldering Machine 110V/ 220V
1500W Handheld Laser Welding Machine Laser Metal Soldering Machine 110V/ 220V
Specifications
Brand Name :
Super Fast-CK
Model Number :
CK-FW-1500W
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 set
Price :
14300USD-18600USD
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
100 sets/month
Delivery Time :
8-10 days
Packaging Details :
Plywood case
Name :
Laser welding machine
Application :
Laser metal weld
Power Supply :
110/220V
Keywords :
Fiber Laser Welding Equipment
Cooling method :
Water-cooling
Description

1500W Handheld Laser Welding Machine Laser Metal Soldering Machine 110V/ 220V

Specification List

Item Characteristic Test Condition Minimum value Typical value Maximum Value Unit
1 Power voltage 　 210 220 230 VAC
2 Power consumption 100% output 　 　 7 KW
CK-FW-1500W
3 Working temperature 　 0 　 40 ℃
4 Working humidity 　 10 　 85 ℃
5 Cooling method Water cooling 　
6 Storage temperature 　 -10 　 60 %
7 Product dimension 1500W 1040*600*1190( L * W * H ) mm
8 Product Weight 1500W 244±3 kg

Brief Introduction

The hand-held laser welding equipment uses optical fiber to transmit high-energy-density laser, and it is flexible and convenient to operate by welding the stainless steel, aluminum alloy and other materials through the hand-held welding head. The single-mode continuous fiber laser that Super Fast Laser choose has high beam quality, adopts modular and water-cooled mode, and the system is highly integrated. The laser power is continuously adjustable, free of maintenance and high reliability. Handheld soldering equipment integrates fiber lasers, hand solder joints, laser control systems, safety light extraction systems, and cooling systems. The overall design is small, beautiful, and easy to move, making it easy for customers to choose their work location and range without being limited by space.This welding equipment can be widely used in billboards, metal door frames, water bottles, sanitary ware and mold repair industries.

Material Thickness
mm		 Welding Method 500W Welding Efficiency
(mm/s)		 1000W Welding Efficiency
(mm/s)		 1500W Welding Efficiency
(mm/s)
Stainless Steel 1 Butt welding 40 55 70
Stainless Steel 2 Butt welding 13 35 45
Stainless Steel 3 Butt welding / 18 35
Stainless Steel 4 Butt welding / / 15
Carbon Steel 1 Butt welding 35 48 62
Carbon Steel 2 Butt welding 10 23 35
Carbon Steel 3 Butt welding / 18 25
Carbon Steel 4 Butt welding / / /
1-3 series aluminum alloy 1 Butt welding 30 40 70
1-3 series aluminum alloy 2 Butt welding / 20 35
4-7 series aluminum alloy 1 Butt welding 15 35 60
4-7 series aluminum alloy 2 Butt welding / / 25

After-sale Service of rust cleaner:
1. 3 year guarantee for laser source.
2. Full technical support by e-mail, call and video
3. Lifelong maintenance and spare parts supply.
4. Free design of fixtures as customers required.
5. Free training installation and operation for the staffs.
