A - Grade Cell Monocrystalline PV Solar Panels 200W Snow Resistant For Outdoors
A - Grade Cell Monocrystalline PV Solar Panels 200W Snow Resistant For Outdoors
A - Grade Cell Monocrystalline PV Solar Panels 200W Snow Resistant For Outdoors
A - Grade Cell Monocrystalline PV Solar Panels 200W Snow Resistant For Outdoors
Specifications
Brand Name :
SHINE OR OEM
Model Number :
SN-M180
Certification :
CE, LVD, TUV, IEC, ROSH, SGS
Place of Origin :
CHINA
MOQ :
1
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
20000 pcs per month
Delivery Time :
15 days
Packaging Details :
single box or 25 pieces per pallet
Max power :
180Watt
Voltage :
36V vmp
Current :
5.00A
Efficiency :
14.10%
SIze :
1580*808*35mm
Junction box :
MC4 Connector
Description

Shenzhen manufacturer A-grade cell Monocrystalline Solar Panel high efficiency 200w PV solar panel

There're 7 major inspection procedures for Each piece solar panels during production :

3 times EL testing to ensure panel without micro-break/invisible break ;

3 times appearance inspection to ensure solar panel without defect ;

1 time solar power testing, solar power inspection tolerance +/3watt, we ensure each solar panel has enough solar power output; besides standard inspection, each production procedure will inspect the upwards procedure;

• So we guarantee each piece of our solar energy photovoltaic panel has perfect appearance, positive solar power performance, and without quality hidden trouble.

1. High conversion efficiency solar cells based on innovative photovoltaic technologies.

2. High stability 100% A grade photovoltaic cells with guaranteed +-3% solar power output tolerance,ensuring investment return.

3. Tempered front glass withstands high wind-pressure and snow load.

4. Easy to install.

Product Description

Characteristics SN-M180 SN-M190 SN-M200
Maximum Power(Pmax) 180Wp 190Wp 200Wp
Optimum Operating Voltage/Vmp 36.0V 36.0V 36.0V
Optimum Operating Current/Imp 5.00A 5.26A 5.52A
Open Circuit Voltage /Voc 43.2V 43.2V 43.2V
Short Circuit Current /Isc 5.6A 5.78A 6.07A
Module Efficiency 14.10% 14.88% 15.67%
Weight 14Kg 14Kg 14Kg
Numbers of cells 72(6*12) 72(6*12) 72(6*12)
Cell dimension(mm) 125*125 125*125 125*125
Dimensions(mm) 1580*808*35
Standard test condition Irradiance 1000W/m²,Module temperature 25℃, AM=1.5

Mechanical Characteristics
Power Tolerance ±3 %
Maximum Series Fuse Rating 15A
Maximum System Voltage 1000V DC
Operating Module Temperature -40°C to +80°C
Frame Material Clear Anodized aluminum Frame
Thickness of glass 3.2mm tempered glass
Frame Anodized aluminum alloy
Laminating material EVA
Backsheet material TPT
Junction box Ip65
Mechanical Characteristics
Power Tolerance ±3 %
Maximum Series Fuse Rating 15A
Maximum System Voltage 1000V DC
Operating Module Temperature -40°C to +80°C
Frame Material Clear Anodized aluminum Frame
Thickness of glass 3.2mm tempered glass
Frame Anodized aluminum alloy
Laminating material EVA
Backsheet material TPT
Junction box Ip65

Temperature Characteristics
Norminal Operating Cell Temperature(NOCT) 45±2℃
Temperature Coefficient of Pmax -0.45%/2℃
Temperature Coefficient of Voc -0.34%/2℃
Temperature Coefficient of Isc -0.050%/2℃
