Customized SunPower Flexible Solar Panels , Flexible Solar Panels Marine 50W
Customized SunPower Flexible Solar Panels , Flexible Solar Panels Marine 50W
Customized SunPower Flexible Solar Panels , Flexible Solar Panels Marine 50W
Customized SunPower Flexible Solar Panels , Flexible Solar Panels Marine 50W
Specifications
Brand Name :
SHINE OR OEM
Model Number :
SN-H50W
Certification :
CE, RoHS, SGS, LVD
Place of Origin :
China
MOQ :
1
Price :
negiotation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
10000 pcs per month
Delivery Time :
5-8 days
Packaging Details :
10 pcs per carton and then on pallet.
Front material :
High Efficiency SunPower cells
Size :
545*535*3mm
Weight :
0.5KGS
Color :
White or Black
Junction box :
IP67 with Diodes
Connectors :
90cm with MC4 connectors
Features :
Corrosion Resistant, Flexible, Portable
Application :
Boat/ RV /Vehicle/Home
Description

High efficience 50W flexible Solar Panel with high efficience sunpower flexible solar cell

The Semi-Flexible solar panel are made by the high efficiency solar cell, it widely apply for the outdoor sports, travel, camping, etc. The solar panel 12V can as the battery charger, 18650 battery charger, AA/AAA rechargeable charger and the USB/car charger. After connecting the controller, the solar panel can charging the cell phone, laptop, iphone, ipad, mobile phone,etc.

Feature:

** Highest efficiency available - genuine A Grade Maxeon Gen III cells are supplied directly by Sunpower to our manufacturer
*** IV curve test with flash sun simulator checks that the panel outputs the rated power.
*** PET top layer for UV protection
*** Textured surface for robustness
*** Lightweight
*** Install using double sided high bond tape or adhesive sealant.
*** Eyelets are optional.
Our server

1.Your inquiry related to our products or prices will be replied in 24hrs.
2.Well-trained and experienced staffs to answer all your enquires in fluent English
3.OEM&ODM, any your customized lightings we can help you to design and put into product.
4.Distributoership are offered for your unique design and some our current models.
5.Protection of your sales area, ideas of design and all your private information.

50W Flexible solar panel:

  • Size: 545*535*3MM
  • Material: SunPower Monocrystalline Silicon
  • Number of Cells: 32PCS
  • Max. Power: 50W
  • Nominal Capacity: 50W
  • Pmax(Power at Maximum under STC): 50W
  • Ipm(Current at Max Power, A): 2.84A
  • Vmp(Voltage at Max Power, V): 17.6V
  • Voc(Voltage at Open Circuit, V): 21.6V
  • Isc(Current at Short Circuit,A): 3.05A
  • STC(Standard Testing Condition): 1000W/Square Meter AM=1.5 25 C Degree
  • Max System Voltage: 700VDC
  • Connection Method: 0.9M Cable with terminals
  • Solar Cell Efficiency: 22.0%
  • Customized: Yes

Other model and wattage:

Sunpower Semi-Flexible Solar Panel
MODEL PM/W VOC/V ISC/A VMP/V IMP/A N/W(kg) DIMENSION
(mm)
SN-H18W 18.00 23.70 1.03 19.40 0.93 0.32 434*277*3
SN-H20W 20.00 25.00 1.05 20.80 0.96 0.36 455*277*3
SN-H25W 25.00 21.60 1.50 18.00 1.40 0.45 560*277*3
SN-H30W 30.00 21.20 1.83 17.60 1.70 0.54 535*378*3
SN-H50W 50.00 21.20 3.05 17.60 2.84 0.90 545*535*3
SN-H60W 60.00 21.00 3.84 17.50 3.43 1.08 725*535*3
SN-H90W 90.00 18.50 6.30 15.20 5.90 1.60 920*540*3
SN-H100W 100.00 21.60 5.97 17.80 5.62 1.80 1050*540*3
SN-H110W 110.00 23.70 5.91 19.80 5.56 1.98 1175*540*3
SN-H120W 120.00 26.40 5.87 22.00 5.45 2.16 1305*540*3
SN-H135W 135.00 29.50 5.82 24.90 5.45 2.43 1435*540*3
SN-H150W 150.00 32.00 5.90 27.40 5.50 2.70 1300*660*3
SN-H180W 180.00 40.00 6.00 33.00 5.45 3.24 1300*800*3
SN-H200W 200.00 42.00 6.30 35.00 5.70 3.60 1435*800*3
SN-H220W 220.00 48.30 5.90 39.80 5.45 3.96 1560*800*3
SN-H250W 250.00 54.00 6.10 45.00 5.60 4.50 1810*800*3
SN-H300W 300.00 66.00 6.50 55.00 5.45 5.40

1810*920*3
