Specifications
Brand Name :
RYDBATT
Model Number :
RYD-16LTR
Certification :
CE
Place of Origin :
CHINA
MOQ :
500
Delivery Time :
45
Price :
Negotiated The Price
Payment Terms :
D/P, T/T,
Supply Ability :
800PCS /Day
Packaging Details :
Customer requirements
Type :
Li-Ion
Size :
Other
Cycle life :
500-1000 Times
Application :
electric bicycle
Voltage :
60V
Cell :
Panasonic/Samsung/LG/Local cell
Oem :
Acceptable
Description

MODEL

16LTR-30C -M603-ZN

SHENZHEN RYDER ELECTRONICS CO., LTD.

60V Electric Motor Battery Pack / Lithium Ion Battery For Electric Motor60V Electric Motor Battery Pack / Lithium Ion Battery For Electric Motor60V Electric Motor Battery Pack / Lithium Ion Battery For Electric Motor

Cell Protection Board: MS6050-03-V01 / 16S150A -RS485/SW16S30C5L-ZN02

Communication Protocol: RS485

Fault State Detection: YES

SOC Display: YES

Product specifications

NO. Items Specifications Remarks
1 Product Weight 11KG±0.5
Product Size 200*150*300mm
2 Rated Output Standard value 30.0Ah 0.5C Discharge Standard
Minimum value
3 Shipping Voltage &60V m80%POWER
4 Rated Voltage 60V
5 Discharge Cut-Off Voltage 44.8V Discharge termination voltage
6 Charge Cut-Off Voltage 67.2V
7 Finished Product Impedance M200mQ At 50% capacity with 1 kHz AC test value
8 Standard Charging Current <12A
9 Maximum Charge Current 15A
10 Standard Discharge Current 20A
11 Maximum Continuous Discharge Current 50A 1.5C
12 Short Circuit Protection YES
13 Short-Circuit Protection Recovery Method Disconnect the load
14 Soft Switch Function YES
15 Prefilled Output Switch Function YES

Protection Plate Configuration

60V Electric Motor Battery Pack / Lithium Ion Battery For Electric Motor

NO. Items Content
1 Model TOPBAND
2 Hardware Board Coding 6050-03-V01
3 Software Release SW16S30C5L-ZN02
4 Charge Discharge Function No charge/discharge trigger
5

Hardware

Functionality

 16 S /50A /485 communication/two-way weak current switch
6 Functional Description Overcharge protection, over discharge protection, overload protection, short circuit protection, output soft switching function, pre charge control function.


18650 Batteries


Some things to consider when choosing a battery:

Style
Flat Top - The positive end of the battery is a flat surface.
Button Top - The positive end of battery is protruding.
Nominal Capacity
This is the minimum capacity of the battery.
Capacity is measured by mAh (Milliamp Hours).
mAh is a unit for measuring electrical power over time.
A higher mAh rating means the (fully-charged) battery can power a device that consumes more power and/or for a longer amount of time before becoming depleted and needing to be re-charged
Continuous Discharge Rating
The maximum current at which the battery can be discharged continuously without damaging the battery or reducing its capacity as defined by the manufacturer.
Pulse Discharge Rating
The maximum current at which the battery can be discharged for a short period of time without damaging the battery or reducing its capacity as defined by the manufacturer.
Nominal Voltage
A value assigned for classification purposes. Operation may actually be possible within a range, and the nominal voltage is often the midpoint of that range.
Protected
Protected batteries have a small electronic circuit integrated into the cell packaging. This circuit protects the battery against common dangers, such as overcharge, over discharge, short circuit/over current, and temperature. Please keep in mind a protected battery will be slightly longer do to the integrated circuit.
