25.4mm Optical Glass Filters 50 Scratch Dig Absorptive Neutral Density Filter

Specifications

Brand Name :

STAR OPTIC

Model Number :

NDF-A

Certification :

RoHS, ISO9001

Place of Origin :

Wuhan, China

MOQ :

Negotiable

Price :

Negotiable

Payment Terms :

T/T, Western Union, Paypal

Supply Ability :

50000pcs/Month

Delivery Time :

Negotiable

Packaging Details :

Safe and dust-free packing

Product Name :

Absorptive Neutral Density (ND) Filter

Usage :

control light density enters the camera’s sensor

Applications :

monochromatic and color cameras

Wavelength range :

400-700nm

Size :

round 25.4mm, square 50x50mm

Optical Density :

0.1-4.0

Description

Absorptive Neutral Density (ND) Filter

Overview:

Absorptive Neutral Density (ND) filters is a type of dark filters that easily attaches to the front of a camera lens, to control how much light enters the camera’s sensor. Since a neutral density filter only affects light levels, it doesn’t have any impact on image colour, contrast or sharpness.

Essentially, it’s like a volume control for light. By reducing the amount of light that comes through your camera lens, a neutral density filter lets you shoot in harsh lighting conditions and manipulate your photos to achieve really creative results.

The Absorptive neutral density (ND) filters can be used with both monochromatic and color cameras.

General Specifications Of Absorptive Neutral Density (ND) Filter:

Material	Absorptive Glass
Dimension Tolerance	+0.0/-0.2mm
Surface Quality	80/50 scratch and dig
Clear Aperture	>90%
Flatness	<2λ@632.8nm
Parallelism	<5 arc minutes
Chamfer	Protective<0.5mmx45°
OD Tolerance	OD±10%@Design Wavelength

Standard Products Of Absorptive Neutral Density (ND) Filter:

PN.	Dimension (mm)	OD	Transmission (%)	Design Wavelength (nm)
ANDF25-0.1-400-700	25.4	0.1	79	400-700nm
ANDF25-0.2-400-700	25.4	0.2	63	400-700nm
ANDF25-0.3-400-700	25.4	0.3	50	400-700nm
ANDF25-0.4-400-700	25.4	0.4	40	400-700nm
ANDF-25-0.5-400-700	25.4	0.5	32	400-700nm
ANDFA25-0.6-400-700	25.4	0.6	25	400-700nm
ANDFA25-0.7-400-700	25.4	0.7	20	400-700nm
ANDF25-0.8-400-700	25.4	0.8	16	400-700nm
ANDF25-0.9-400-700	25.4	0.9	13	400-700nm
ANDF25-1.0-400-700	25.4	1.0	10	400-700nm
ANDF25-2.0-400-700	25.4	2.0	1	400-700nm
ANDF25-3.0-400-700	25.4	3.0	0.1	400-700nm
ANDF25-4.0-400-700	25.4	4.0	0.01	400-700nm
ANDF5050-0.1-400-700	50X50	0.1	79	400-700nm
ANDF5050-0.2-400-700	50X50	0.2	63	400-700nm
ANDF5050-0.3-400-700	50X50	0.3	50	400-700nm
ANDF5050-0.4-400-700	50X50	0.4	40	400-700nm
ANDF5050-0.5-400-700	50X50	0.5	32	400-700nm
ANDF5050-0.6-400-700	50X50	0.6	25	400-700nm
ANDF5050-0.7-400-700	50X50	0.7	20	400-700nm
ANDF5050-0.8-400-700	50X50	0.8	16	400-700nm
ANDF5050-0.9-400-700	50X50	0.9	13	400-700nm
ANDF5050-1.0-400-700	50X50	1.0	10	400-700nm
ANDF5050-2.0-400-700	50X50	2.0	1	400-700nm
ANDF5050-3.0-400-700	50X50	3.0	0.1	400-700nm
ANDF5050-4.0-400-700	50X50	4.0	0.01	400-700nm

Spectrum Graphs of Absorptive Neutral Density (ND) Filter:

400-700nm Absorptive ND filter OD0.1
